Associated Numbers
0124415030Specifications
| B+ Stud Diameter & Thread Pitch (B+d) | M6x1.0 mm |
| B+ Thread Length (B+H) | 21.5 mm |
| Diode Amp Rating | 50 A |
| Diodes (Main) | 6 qty |
| D+ Stud Diameter & Thread Pitch (D+d) | M8x1.25 mm |
| D+ Thread Height (D+H) | 8.4 mm |
| Inside Diameter (I.D.1) | 38 mm |
| Mount Distance (C-C) | 100 mm |
| Outside Diameter (O.D.1) | 120.5 mm |
| Reg/Rec Combo | No |
| Source | ∆ |
| Unit Type | BOSCH |
| With Attached Bracket | No |
