Associated Numbers
0120469549 0120469634 0120469673 0120469679 0120469691 0120469849 0120469890Specifications
| B+ Stud Diameter & Thread Pitch (B+d) | M6x1.0/M8x1.25 mm |
| B+ Thread Length (B+H) | 34.5 mm |
| Diode Amp Rating | 50 A |
| Diodes (Main) | 8 qty |
| D+ Stud Diameter & Thread Pitch (D+d) | M4x0.7 mm |
| D+ Thread Height (D+H) | 22.5 mm |
| Inside Diameter (I.D.1) | 35 mm |
| Outside Diameter (O.D.1) | 123 mm |
| Reg/Rec Combo | No |
| Unit Type | BOSCH |
| With Attached Bracket | No |
Reference Information
231218 216158 CQ1080609 1127320517 1127320603 RTF50009 RCT1175 81114441Video/Publications
120469634 0120469691 0120469890 216158 120469673 120469691 120469890 0120469634 81114441 0120469673 0120469849 231218 0120469679 0120469549 CQ1080609 1127320517 1127320603 RTF50009 120469849 120469549 120469679Add Your Number
