Associated Numbers
0120469788 0120469789 B120500315Specifications
| B+ Stud Diameter & Thread Pitch (B+d) | M8X1.25 M6x1.0 mm |
| B+ Thread Length (B+H) | 34.6 mm |
| Diode Amp Rating | 35 A |
| Diodes (Main) | 8 qty |
| D+ Stud Diameter & Thread Pitch (D+d) | M5x0.8 mm |
| D+ Thread Height (D+H) | 22 mm |
| Inside Diameter (I.D.1) | 36.6 mm |
| Outside Diameter (O.D.1) | 123.3 mm |
| Reg/Rec Combo | No |
| Unit Type | BOSCH |
| With Attached Bracket | No |
Reference Information
CQ1080156 1127320716 RCT1188 81112791 233779Video/Publications
CQ1080156 120469788 0120469789 B120500315 1127320716 0120469788 81112791 233779 120469789Add Your Number
