Associated Numbers
0124325066 0124325076Specifications
| B+ Stud Diameter & Thread Pitch (B+d) | M8X1.25 mm |
| B+ Thread Length (B+H) | 6.6 mm |
| Diode Amp Rating | 50 A |
| Diodes (Main) | 6 qty |
| D+ Stud Diameter & Thread Pitch (D+d) | M8X1.25 mm |
| D+ Thread Height (D+H) | 20.2 mm |
| Inside Diameter (I.D.1) | 39 mm |
| Mount Distance (C-C) | 100 mm |
| Outside Diameter (O.D.1) | 122.5 mm |
| Reg/Rec Combo | No |
| Source | Y |
| Unit Type | BOSCH |
| With Attached Bracket | No |
Reference Information
RB-172H F00M123249 IBR209 RCT1235Video/Publications
0124325066 0124325076 A0329 124325076 0124225054 124325066 RB-172H F00M123249 124225054Add Your Number
