Associated Numbers
0120488186 0120488187 B120402578Specifications
B+ Stud Diameter & Thread Pitch (B+d) | M6x1.0 mm |
B+ Thread Length (B+H) | 38.5 mm |
Diode Amp Rating | 35 A |
Diodes (Main) | 6 qty |
D+ Stud Diameter & Thread Pitch (D+d) | M5x0.8 mm |
D+ Thread Height (D+H) | 31 mm |
Inside Diameter (I.D.1) | 36.7 mm |
Outside Diameter (O.D.1) | 112 mm |
Reg/Rec Combo | No |
Unit Type | BOSCH |
With Attached Bracket | No |
Reference Information
RB-18H CRC10104AS 133998 IBR322 CQ1080383 RTF39722 1127320914 21101401BN 1205572 SRC10104 RCT1114 90350009 81112815 REC-206 REC-215 139122Video/Publications
RB-18H 120488186 CRC10104AS 120488187 133998 IBR322 CQ1080383 RTF39722 1127320914 21101401BN 1205572 B120402578 SRC10104 0120488187 90350009 0120488186 81112815 REC-206 REC-215 139122Add Your Number
