Associated Numbers
0124325030 0124325062 0124325072Specifications
| B+ Stud Diameter & Thread Pitch (B+d) | M8X1.25 mm |
| B+ Thread Length (B+H) | 21.2 mm |
| Diodes (Main) | 6 qty |
| D+ Stud Diameter & Thread Pitch (D+d) | M8X1.25 mm |
| D+ Thread Height (D+H) | 12.4 mm |
| Outside Diameter (O.D.1) | 120.5 mm |
| Reg/Rec Combo | No |
| Source | WYE |
| Unit Type | BOSCH |
| With Attached Bracket | No |
Reference Information
F00M123210 RCT1040 133717 F00M123347Video/Publications
124325072 F00M123210 124325062 124325030 0124325062 0124325072 0124325030 133717 F00M123347Add Your Number
