Associated Numbers
0120468009 0120468010 0120468011 0120468012 0120468015 0120468016 13634977 13635107 50036425Specifications
| B+ Stud Diameter & Thread Pitch (B+d) | M6x1.0/M8x1.25 mm |
| B+ Thread Length (B+H) | 34 mm |
| Diode Amp Rating | 35 A |
| Diodes (Main) | 6 qty |
| D+ Stud Diameter & Thread Pitch (D+d) | M5x0.8 mm |
| D+ Thread Height (D+H) | 22 mm |
| Inside Diameter (I.D.1) | 36.5 mm |
| Mount Distance (C-C) | 65 mm |
| Outside Diameter (O.D.1) | 123.5 mm |
| Reg/Rec Combo | No |
| Unit Type | BOSCH |
| With Attached Bracket | No |
Reference Information
940038367 CQ1080058 REC-240 138620 IBR713 RTF39759 1127320713 RCT1148 139351Video/Publications
13634977 120468016 940038367 CQ1080058 120468015 120468012 50036425 13635107 120468010 120468011 0120468012 0120468011 0120468010 0120468016 0120468015 0120468009 REC-240 138620 IBR713 RTF39759 1127320713 120468009 139351Add Your Number
