Associated Numbers
0986080690 20130190 28-1812 28-3572 28-5879 37300-36015 37300-36030 37300-43360 37300-43860 40870RI 600043 600047 66021305 89212216 A003T08293 A3T08293 A3T08376 A3T45794 A3TA1391 AB190097 AB190205 AB190386 AEA2233 DRA3188 JA870IR LRA01387 LRA01772 MD149751 MD168988 MD168989 MD189014 PXPAA-523 UD02556A UD11329A
MXA226
0986080690 Bosch ruil
12060178 EuroTec
155528090 PSH
281812 Elstock
285879 Elstock
3730036030 Kia
3730043850 Kia
3730043860 Kia
5444SP Spidan
600040 Valeo
600043 Valeo
600047 Valeo
90273188 Wilson
933188 EDR
A003T08293 Mitsubishi
A003T45794 Mitsubishi
A003TA1391 Mitsubishi
A3T08293 Mitsubishi
A3T45794 Mitsubishi
A3TA1391 Mitsubishi
AB190097 Valeo
AB190205 Valeo
ACA347 ATK
ALT5067sa Electrolog
ALT5073sa Electrolog
DRA3188 Remy
HJA870IR HC
J5110502 Nipparts
JA870IR HC
L69040 ATL
LRA03267 Lucas
MD149751 Mitsubishi
MD168989 Mitsubishi
MD189014 Mitsubishi
N5110326 Nipparts
TRA079 TWA
Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | M8x1.25 mm |
| Diameter (D.3) | 8.5 mm |
| Diameter (D.4) | 8.5 mm |
| Grooves | 5 qty |
| Length (L.1) | 160 mm |
| Mount Inside Length or Pad Mount C-C (C) | 55 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 60 mm |
| Plug Code | PL_2004 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 38 mm |
| Pulley Type | SOLID |
| Unit Type | HYUNDAI / KIA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | Galloper 3.0 i V6 | [6G72] | 01.1991-12.1998 |
| HYUNDAI | Galloper 3.0 i V6 | [G6AT] | 01.1997-12.2001 |
| HYUNDAI | H100 2.4 | [G4CS] | 01.1993-12.2000 |
| MITSUBISHI | Pajero 3.0 V6 | [6G72] | 01.1990-12.1994 |
Reference Information
2D982 PXPAA-523 37300-36030 JA870IR LRA01387 37300-43360 LRA1772 20130190 DRA3188 UD02556A AB190386 A3T08376 A3T08293 ALT5073 ALT6360 ALT01034 002-D982 LRA01772 CGB-13188 MD168989 37300-43850 MD168988 A003T45794 446827 A3TA1391 28-1812 66021305 ALTF217 002-C347 MD149751 89212216 0986080690 ALC347 37300-43860 AB190205 40870RI MD189014 600043 2C347 600047 37300-36015 A12MH0663A2 AEA2233 ALD982 A003T08293 UD11329A A003TA1391 LRA1387 A003T08376 28-5879 A3T45794 AB190097 ALT6310 28-3572 986080690Video/Publications
002-C347 002-D982 0986080690 20130190 28-1812 28-3572 28-5879 2C347 2D982 37300-36015 37300-36030 37300-43360 37300-43860 40870RI 600043 600047 66021305 89212216 A003T08293 A3T08293 A3T08376 A3T45794 A3TA1391 AB190097 AB190205 AB190386 AEA2233 ALC347 ALD982 ALT6310 ALT6360 ALTF217 CGB-13188 DRA3188 JA870IR LRA01387 LRA01772 LRA1387 LRA1772 MD149751 MD168988 MD168989 MD189014 PXPAA-523 UD02556A UD11329AAdd Your Number
