Associated Numbers
37300-51000 90-31-7022 A-80175 AD111457 PXPAA-806 TA000A38201 UD02583ASpecifications
| Amp | 110 A |
| Diameter (D.1) | M12x1.25 mm |
| Diameter (D.2) | 12.5 mm |
| Diameter (D.3) | 12.5 mm |
| Grooves | 7 qty |
| Length (L.1) | 269 mm |
| Outside Diameter (O.D.1) | 77 mm |
| Pivot Foot Length (B) | 13 mm |
| Pivot Inside Length (C) | 81 mm |
| Plug Code | PL_2004 |
| Pulley Type | SOLID |
| Pulley to Mount Distance (A) | 37.5 mm |
| Unit Type | MANDO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BERING | LD Series | [638] | 01.1997-12.2001 |
Reference Information
90-31-7022 A-80175 AD111457 PXPAA-806 TA000A38201 37300-51000 UD02583AVideo/Publications
