Associated Numbers
0986AR0761 11.1718 11001N 113517 20130174 20193701BN 20193701OE 20193701RE 2032107 28-4597 28-4637 37300-38310 37300-38700 37300-38710 401718RI 57181 8EL738106-001 9060511 9212556 A9017 AB195141 AEB1718 ALT35017 CAL32107AS CAL32107GS CAL32107OS DRA4177 JA1718IR LRA02178 SB121 TA000A44301Specifications
Amp | 95 A |
Bottom Mounting Foot Width (B) | 13 mm |
Diameter (D.1) | 10.5 mm |
Diameter (D.2) | M8x1.25 mm |
Diameter (D.3) | 10.5 mm |
Grooves | 4 qty |
Length (L.1) | 180 mm |
Mount Inside Length or Pad Mount C-C (C) | 67 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 60 mm |
Plug Code | PL_4100 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 39 mm |
Pulley Type | SOLID |
Unit Type | HYUNDAI / KIA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | Santa F 2.0 | [G4BP] | 08.2001-09.2002 |
HYUNDAI | Santa F 2.4 16V | [G4JS-G] | 02.2000-09.2002 |
HYUNDAI | Santa F 2.4 16V 4WD | [G4JS-G] | 02.2000- |
HYUNDAI | Trajet 2.0 | [G4JP-G] | 01.2000- |
Reference Information
A003TA5492AM 9212556 A3TB0291 CAL32107OS AEB1718 ALTW038 57181 MD374904 ALT35017 20193701RE A9017 DMX142087 28-4637 11.1718 MD358421 CAL32107GS 28-4597 MD343416 A003TA5491 A003TA7791 A003TA5492 A3TB5191 LRA2178 CGB-15126 A12HY0469A2 SB121 11001N 37300-38700 8EL738106-001 37300-38310 ALC982 AB195141 002-C982 LR1100736C LRA02178 A3TB4191 113517 20193701OE MD358607 00986AR0761 DRA4177 20130174 CAL32107AS A003TB5191 ANM36397X MD360635 37300-38710 2C982 9060511 ALT6480 0986AR0761 401718RI A3TA5492AM JA1718IR A3TA5491 A3TA7791 20193701BN A3TA5492 ALT8730 A003TB0291 2032107 37300-38400 TA000A44301 MD347904 11027NVideo/Publications
002-C982 0986AR0761 11.1718 11001N 11027N 113517 20130174 20193701BN 20193701OE 20193701RE 2032107 28-4597 28-4637 2C982 37300-38310 37300-38400 37300-38700 37300-38710 401718RI 57181 8EL738106-001 9060511 9212556 A9017 AB195141 AEB1718 ALC982 ALT35017 ALT6480 ALTW038 CAL32107AS CAL32107GS CAL32107OS CGB-15126 DRA4177 JA1718IR LRA02178 LRA2178 SB121 TA000A44301Add Your Number
