Associated Numbers
0986049051 11.1600 11.1600M 111847 20110431 20160101OE 20160101RE 2046101 21431N 21431R 219170 219235 219251 219292 2655476 28-3866 28-5668 302023RI 302023RIV 401600RI 401600RIV 553288RI 553946RI 56938 600001 8EL011711-201 8EL737917-001 9060908 9450 96289030 96314258 96380673 96404263 96518124 96566261 96567255 A9004 AB165104 AEA4231 AEK2999 ALT35002 CAL46101GS CAL46101OS CAL46112AS DRA3824 DRA3824N EAA-221046 F042A0B009 G101600MA-R GA314258-A JA1600IR LRA02999 LRB00431 P96566261 RAA14935 SA239 SB249 TA000A52202Specifications
| Amp | 65 A |
| Bottom Mounting Foot Width (B) | 15 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | 8.5 mm |
| Grooves | 1 qty |
| Groove Width (W.1) | 9 mm |
| Length (L.1) | 162 mm |
| Mount Inside Length or Pad Mount C-C (C) | 65 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 43 mm |
| Outside Diameter (O.D.2) | 69 mm |
| Plug Code | PL_2600 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 42.5 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DAEWOO | Matiz 0.8 | [F8CV] | 01.1998- |
| DAEWOO | Matiz 1.0 | [B10S] | 01.2003- |
Reference Information
DA4934N ALTL084 CAL46101OS AG0267 235.502.065.360 96518124 9372008500 9.44391E+11 CAL46101GS ALA1600 GA314258-A 96567255 20160101RE AB165104 28-3866 DA4934 GA165104MA-R 56938 ANM36044X DRA3824 235.502.065.038 ALM1600 31400-A78B02 STA0131R ALT390 MQA1600 ALD1600 21431N AEA4231 ALD5600 219251 200113 440122 219170 2046101.4 63731600010 ALT2610 A9004 20160101OE EAA-221046 GA314258DE-R ALT8712 55151062 96404263 20160101BN ALZ460 2046101.1 ALT7020 MRA60908 96566262 986049051 96380673 96566261 LRB431 TA000A30601 63532620010 235.502.065 PRAL084 225-10124 0986049051 20110431 CGB-13034 401600RI 8EL737917-001 CAL46101AS 235.502.065.415 210208 002-Z460 DRA3824N 96314258 600001 DRA3824X RNL1600JA 96289030 ALT35002 235.502.065.390 2046101 235.502.065.030 LRB00431 114114 401600RIR 9450 2Z460 RAA14935 111847 401600RIV TA000A52202 9.4332E+11 446649 JA1600IR ALT00891Video/Publications
002-Z460 063532620010 063731600010 0986049051 114114 200113 20110431 20160101BN 20160101OE 20160101RE 2046101.0 2046101.1 2046101.4 210208 21431N 219170 219251 225-10124 235.502.065 28-3866 2Z460 401600RI 401600RIR 401600RIV 440122 56938 600001 8EL737917-001 943320231010 944390609080 9450 96314258 96380673 96518124 96566261 A9004 AB165104 AEA4231 AG0267 ALA1600 ALD1600 ALD5600 ALM1600 ALT35002 ALT390 ALT7020 ALZ460 CAL46101AS CAL46101GS CAL46101OS CGB-13034 DA4934 DA4934N DRA3824 DRA3824N DRA3824X EAA-221046 GA165104MA-R GA314258-A GA314258DE-R JA1600IR LRB00431 LRB431 MQA1600 MRA60908 PRAL084 RAA14935 RNL1600JA TA000A52202Add Your Number
