Associated Numbers
021000-3840 ALN0137 JA137 UD16859A 0986032591 CAL40281AS 9220 DRA2591 DA3701 021000-0046 021000-0047 021000-0064 021000-0132 021000-0133 021000-0134 021000-0180 021000-0183 021000-0184 021000-0186 021000-0187 021000-0240 021000-0247 021000-0318 021000-0327 021000-0350 021000-0351 021000-0360 021000-0361 021000-0362 021000-0363 021000-0364 021000-0369 021000-0370 021000-0371 021000-0372 021000-0461 021000-0501 021000-0529 021000-0532 021000-0590 021000-0591 021000-1053 021000-1350 021000-1351 021000-1352 021000-1891 021000-1892 021000-2411 021000-3220 021000-3730 021000-3731 021000-3750 021000-3810 021000-3880 021000-3900 021000-3910 021000-3930 021000-3950 021000-3960 021000-3980 021000-3990 021000-4030 021000-4060 021000-4061 021000-4070 021000-5100 021000-5101 021000-5111 021000-5190 021000-5210 021000-5220 021000-5280 021000-5290 021000-5910 021000-5950 021000-5960 021000-6020 021000-6050 021000-6051 021000-6060 021000-6061 021000-6101 021000-6151 021000-6152 021000-6160 021000-6550 021000-6551 021000-6600 021000-6610 021000-6611 021000-6612 021000-6630 021000-6631 021000-6632 021000-6640 021000-6641 021000-6642 021000-6643 021000-6660 021000-6682 021000-6700 021000-6710 021000-6711 021000-6712 021000-6732 021000-6740 021000-6750 021000-6770 021000-6771 021000-7240 021000-8021 021000-8030 021000-9250 100211-0530 A-8026 146-32101 55671 27-0596 209484 40137 40137R LRA00167 943346050010 MAR6050 943356921010 MAR973 943356934010 MAR986 89213679 195.004.050 20132182BN 290-10396 2040281.0 27020-12040 27020-13013 27020-13022 27020-13290 27020-21011 27020-24070 27020-26080 27020-26100 27020-26110 27020-26111 27020-26120 27020-26121 27020-26150 27020-31010 27020-31011 27020-31080 27020-31110 27020-31111 27020-31120 27020-31132 27020-34010 27020-34011 27020-34012 27020-34020 27020-34021 27020-34050 27020-34051 27020-36080 27020-38010 27020-38020 27020-38021 27020-38022 27020-38030 27020-38031 27020-38040 27020-38041 27020-38070 27020-39020 27020-40061 27020-41010 27020-41011 27020-41012 27020-41013 27020-41020 27020-41031 27020-41032 27020-41033 27020-41034 27020-41040 27020-41041 27020-41051 27020-41061 27020-41071 27020-41080 27020-41081 27020-41082 27020-45010 27020-45011 27020-45012 27020-45020 27020-45021 27020-45022 27020-45023 27020-45030 27020-45031 27020-45040 27020-45041 27020-45050 27020-45051 27020-45061 27020-45070 27020-45071 27020-45072 27020-45080 27020-45081 27020-45082 27020-45110 27020-45120 27020-45140 27020-61020 27020-61021 27020-61022 27020-61023 27060-34020 436526 14130N 90-29-5010 ALT30049Specifications
Amp | 50 A |
Bottom Mounting Foot Width (B) | 12 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | 10 mm |
Grooves | 1 qty |
Groove Width (W.1) | 10 mm |
Length (L.1) | 165 mm |
Mount Inside Length or Pad Mount C-C (C) | 75.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 46.5 mm |
Outside Diameter (O.D.2) | 70 mm |
Plug Code | PL_3601 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 43.5 mm |
Pulley Type | SOLID |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BMW | 320 2.0 D | [M47D20] | 04.1998-09.2001 |
DAIHATSU | Charade 1.0 | [CB20] | 02.1981-02.1983 |
DAIHATSU | Charade 1.0 | [CB20] | 10.1977-02.1981 |
DAIHATSU | Charade 1.0 | [CB22] | 02.1981-02.1983 |
MASERATI | Kyalami | [107.21.42] | 04.1976-12.1985 |
MASERATI | Quattroporte | [107.22.49] | 08.1979-12.1989 |
MASERATI | Quattroporte 2.0 Biturbo | [24VDOHC] | 03.1994-09.1998 |
PEUGEOT | 605 2.5 TD | [DK5ATE] | 07.1994-09.1999 |
TOYOTA | Carina 1.6 | [2T] | 01.1978-09.1983 |
TOYOTA | Carina 1.6 | [2T] | 03.1981-01.1982 |
TOYOTA | Carina 1.6 | [2TB] | 10.1975-03.1978 |
TOYOTA | Carina 1.8 | [3T] | 01.1982-09.1983 |
TOYOTA | Celica 1.6 GT | [2T-G] | 04.1978-07.1981 |
TOYOTA | Celica 1.6 GT | [2T-G] | 04.1980-07.1981 |
TOYOTA | Celica 1.6 LT | [2TB] | 02.1979-07.1981 |
TOYOTA | Celica 1.6 LT | [2TJ] | 05.1973-03.1978 |
TOYOTA | Celica 1.6 ST | [2T] | 02.1979-07.1981 |
TOYOTA | Celica 1.6 ST | [2TB] | 08.1977-07.1981 |
TOYOTA | Celica 1.6 ST | [4A-L] | 08.1977-07.1981 |
TOYOTA | Celica 2.0 | [18R-G] | 01.1982-12.1985 |
TOYOTA | Celica 2.0 | [21R-U] | 01.1982-12.1985 |
TOYOTA | Celica 2.0 XT | [18R] | 01.1980-07.1981 |
TOYOTA | Celica 2.0 XT | [18R] | 02.1979-07.1981 |
TOYOTA | Celica 2.0 XT | [21R-C] | 02.1982-08.1985 |
TOYOTA | Corolla 1.6 | [2T] | 09.1979-05.1983 |
TOYOTA | Corolla 1.6 | [2T] | 10.1982-09.1983 |
TOYOTA | Corolla 1.6 | [2TB] | 09.1979-05.1983 |
TOYOTA | Corona 1.8 | [3T] | 06.1979-07.1981 |
TOYOTA | Corona 2.0 | [18R] | 01.1976-05.1979 |
TOYOTA | Corona 2.0 | [18R] | 09.1975-05.1979 |
TOYOTA | Cressida 2.0 | [18R] | 12.1977-03.1981 |
TOYOTA | Cressida 2.0 | [21R] | 02.1981-03.1985 |
TOYOTA | Cressida 2.0 | [21R] | 09.1980-04.1985 |
TOYOTA | Cressida 2.0 | [21R-C] | 09.1980-04.1985 |
TOYOTA | Hiace 2.0 | [18R] | 02.1977-03.1983 |
TOYOTA | Land Cruiser 2.4 | [22R] | 11.1984-05.1993 |
TOYOTA | Land Cruiser 4.2 | [2F] | 01.1975-04.1986 |
TOYOTA | Land Cruiser 4.2 | [2F] | 10.1981-01.1988 |
TOYOTA | Liteace 1.3 | [4K] | 10.1979-09.1985 |
TOYOTA | Liteace 1.3 | [4K] | 10.1979-10.1986 |
TOYOTA | Liteace 1.3 | [4K-C] | 10.1979-10.1986 |
TOYOTA | Liteace 1.5 | [5K] | 10.1985-08.1989 |
TOYOTA | Starlet 1.2 | [3K-H] | 02.1978-09.1982 |
Reference Information
27020-40060 021000-3810 27020-40061 2702024060 27020-41032 27020-41033 27020-18011 27020-40062 27020-41031 27020-18010 2702037011 021000-8021 446639 2702060032 2702060033 27020-41034 2702026150R 2702024050 021000-3930 2702060031 110138 27020-13110-000 27020-41020 LRA00167 27020-31110 27020-31111 A-8026 2702025010 021000-0532 2.70203E+12 27020-41051 UD16859A 2702013021 146-32101 DRA2591 27020-31120 2702036070 2702036071 021000-9250 9.43346E+11 2702034051R 021000-0327 021000-1891 021000-1892 021000-3950 2702024031 2702024030 27020-41040 27020-41041 2702038012 2702038011 27020-31010 021000-8030 27020-31011 27020-31132 021000-0318 27020-41071 021000-0461 2702034021R 27020-31141 2702060070 2702038011XA 2702060071 021000-3730 2702060072 021000-5910 2702060073 021000-3731 27020-41061 2702034020R 40137 2702013110 ALN0137 2702061033 021000-3840 021000-3960 021000-0364 021000-0363 021000-0362 021000-0240 021000-0361 021000-0360 27020-24061-000 27020-31042 27020-32011 27020-31043 27020-31040 27020-31041 021000-3990 021000-3750 021000-0369 021000-0247 27020-41081 27020-21010 27020-21011 27020-41082 021000-0350 ALT421090 021000-0591 021000-0590 27020-41080 021000-3980 021000-2411 0986032591 27020-45110 986032591 021000-1350 021000-5950 021000-1351 021000-1352 021000-0134 021000-0133 021000-0132 89213679 021000-0372 021000-0371 021000-0370 2702034031 27020-33011 290-10396 27020-31071 27020-33010 021000-3880 021000-0047 27020-45012 021000-0046 2.70209E+12 27020-45010 27020-44042 27020-45011 CAL40281AS 27020-33022 27020-31084 27020-33021 27020-33020 27020-24062-000 27020-31080 1515818 2702045080R 021000-6700 002-T374 2702026051 27020-44030 27020-45120 27020-44031 27020-33036 27020-33030 021000-5960 Mar-50 2702026040 021000-0187 021000-0186 27020-45030 021000-0064 27020-45031 021000-0184 JA130 021000-0183 JA131 021000-0180 ALT30049 JA137 27020-34012 27020-34010 27020-34011 ALTF382 27020-33040 90-29-5010 ANM34811X 021000-6600 27020-45023 27020-45140 27020-45020 27020-23010 27020-45021 27020-45022 27020-13210 2702013080 100211-0530 27020-34021 27020-34020 021000-6712 2702026021 2702026022 021000-6710 021000-6711 2702024080 2702024081 MAR973 27020-45050 27020-45051 27020-13220 2702036021 2702013070 27020-34030 27020-34031 021000-1053 2.70201E+12 021000-6740 27020-45041 MAR986 27020-45040 27020-13110 2702013060 55671 021000-3220 021000-6610 2702024062 2702024061 021000-6611 021000-6732 021000-6612 2702024063 27020-45070 27020-45071 27020-45072 021000-6642 27020-34050 021000-6643 27020-34051 021000-6640 021000-6641 2702031043 2702032011 27020-12040 27020-13010 27020-45061 2702031041 27020-13013 2702031042 2702031040 27020-87701 27020-87702 021000-6631 021000-6632 021000-6750 021000-6630 27020-87706 27060-11080 27020-24031 27020-13021 27020-24030 2T374 27020-13020 27020-13022 021000-6660 021000-5210 27020-45081 27020-45082 40137R 27020-45080 021000-6770 021000-6771 27020-36021 27020-25010 27020-26100 209484 27060-34020 2702031071 27020-24050 2702033011 2702033010 021000-6682 27020-60033 27020-60031 27020-60032 27020-26110 27020-25021 021000-5111 27020-26111 27020-13290 27020-13050 27020-24063 27020-24062 27020-24061 27020-24060 2702033022 2702033021 2702033020 9.43357E+11 021000-6550 021000-6551 021000-5220 27020-36043 27020-26120 27020-37011 021000-5101 27020-26121 27020-36041 021000-5100 27020-36042 2702044030 27020-34021-000 27020-13060 27020-24070 2702033030 DA3701 021000-6101 2702044042 2040281 27020-13070 27020-24083 27020-24081 27020-24080 14130N 021000-4030 27020-26020 195.004.050 27020-26021 27020-61110 27020-26022 J5112008 27020-26023 27020-38120 27020-36061 27020-26021-000 27020-36060 27020-13080 LRA167 27-0596 27020-60073 27020-60071 27020-60072 9220 27020-60070 021000-4061 021000-4060 27020-26150 27020-26031 27020-26032 27020-38012 27020-38011 27020-38010 27020-36070 27020-36071 20132182BN 27020-26040 27020-38022 27020-38021 210277 27020-38020 27020-36080 4N4540 27020-61020 021000-5290 27020-26050 27020-61023 27020-26051 021000-6020 27020-61021 27020-61022 27020-38031 27020-38030 ALT374 27020-61031 447104 021000-4070 021000-5280 27020-26060 27020-26061 27020-61033 2702026080R 27020-38041 27020-38040 27020-13010-000 2702040062 2702040060 021000-6160 021000-0501 27020-39020 021000-5190 31100-657-024 27020-26090 27020-26080 021000-6151 021000-7240 ALT6018 021000-6152 2702021010 021000-3910 27020-41010 27020-41011 27020-61180 021000-6060 021000-6061 021000-0529 27020-41012 27020-41013 27020-38070 021000-3900 436526 021000-6051 021000-6050 27020-29010Video/Publications
002-T374 021000-0046 021000-0047 021000-0064 021000-0132 021000-0133 021000-0134 021000-0180 021000-0183 021000-0184 021000-0186 021000-0187 021000-0240 021000-0247 021000-0318 021000-0327 021000-0350 021000-0351 021000-0360 021000-0361 021000-0362 021000-0363 021000-0364 021000-0369 021000-0370 021000-0371 021000-0372 021000-0461 021000-0501 021000-0529 021000-0532 021000-0590 021000-0591 021000-1053 021000-1350 021000-1351 021000-1352 021000-1891 021000-1892 021000-2411 021000-3220 021000-3730 021000-3731 021000-3750 021000-3810 021000-3840 021000-3880 021000-3900 021000-3910 021000-3930 021000-3950 021000-3960 021000-3980 021000-3990 021000-4030 021000-4060 021000-4061 021000-4070 021000-5100 021000-5101 021000-5111 021000-5190 021000-5210 021000-5220 021000-5280 021000-5290 021000-5910 021000-5950 021000-5960 021000-6020 021000-6050 021000-6051 021000-6060 021000-6061 021000-6101 021000-6151 021000-6152 021000-6160 021000-6550 021000-6551 021000-6600 021000-6610 021000-6611 021000-6612 021000-6630 021000-6631 021000-6632 021000-6640 021000-6641 021000-6642 021000-6643 021000-6660 021000-6682 021000-6700 021000-6710 021000-6711 021000-6712 021000-6732 021000-6740 021000-6750 021000-6770 021000-6771 021000-7240 021000-8021 021000-8030 021000-9250 0986032591 100211-0530 110138 14130N 146-32101 195.004.050 20132182BN 2040281.0 209484 27-0596 27020-12040 27020-13013 27020-13022 27020-13290 27020-21011 27020-24070 27020-26080 27020-26100 27020-26110 27020-26111 27020-26120 27020-26121 27020-26150 27020-31010 27020-31011 27020-31080 27020-31110 27020-31111 27020-31120 27020-31132 27020-34010 27020-34011 27020-34012 27020-34020 27020-34021 27020-34050 27020-34051 27020-36080 27020-38010 27020-38020 27020-38021 27020-38022 27020-38030 27020-38031 27020-38040 27020-38041 27020-38070 27020-39020 27020-40061 27020-41010 27020-41011 27020-41012 27020-41013 27020-41020 27020-41031 27020-41032 27020-41033 27020-41034 27020-41040 27020-41041 27020-41051 27020-41061 27020-41071 27020-41080 27020-41081 27020-41082 27020-45010 27020-45011 27020-45012 27020-45020 27020-45021 27020-45022 27020-45023 27020-45030 27020-45031 27020-45040 27020-45041 27020-45050 27020-45051 27020-45061 27020-45070 27020-45071 27020-45072 27020-45080 27020-45081 27020-45082 27020-45110 27020-45120 27020-45140 27020-61020 27020-61021 27020-61022 27020-61023 27060-34020 290-10396 2T374 40137 40137R 436526 55671 89213679 90-29-5010 9220 943346050010 943356921010 943356934010 A-8026 ALN0137 ALT30049 ALT374 ALT421090 ALTF382 CAL40281AS DA3701 DRA2591 J5112008 JA130 JA131 JA137 LRA00167 LRA167 MAR6050 MAR973 MAR986 UD16859A 210277Add Your Number
