Associated Numbers
104210-2950 11626N 20010 23035 555320RI 90-29-5801 A-80534 BR3T-10300-LA BR3T10300LA BR3Z-10346-E BR3Z10346E UD15421ASpecifications
Amp | 150 A |
Bottom Mounting Foot Width (B) | 15 mm |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | M10x1.5 mm |
Grooves | 6 qty |
Length (L.1) | 174 mm |
Mount Inside Length or Pad Mount C-C (C) | 57.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 54 mm |
Plug Code | PL_3402 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Type | SOLID |
Pulley to Mount Distance (A) | 50 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FORD | Mustang 5.0 V8 | 01.2011-12.2014 |
Reference Information
20010 90-29-5801 BR3Z10346E A-80534 BR3T10300LA 23035 104210-2950 555320RI BR3Z-10346-E 11626N UD15421A BR3T-10300-LAVideo/Publications
104210-2950 11626N 20010 23035 555320RI 90-29-5801 A-80534 BR3T-10300-LA BR3T10300LA BR3Z-10346-E BR3Z10346E UD15421AAdd Your Number
