Associated Numbers
0986082010 104210-1860 104210-3410 104210-3411 104210-5440 104210-5441 104211-8741 113969 195.574.100 20132392 20132522 2040225 2040293 210775 24056R 27060-30060 27060-30080 27060-30130 27060-30131 27060-30210 28-5679 553219RI 553219RIM 57033 89215342 9447 ALN3969 ALT30464 CA2069IR CAL40225 CAL40225AS CAL40225ES CAL40225GS CAL40225OS CAL40225RS CAL40293 CAL40293AS CAL40293ES CAL40293GS CAL40293OS CAL40293RS DA1356 DAN1070 DENDAN1070 DRA0246 LRA03067 UD15310A
1042101862 1042101861 1042101860 2706030210 1042101860 2706030210
104210-1862 104210-1861 104210-1860 2706030210 104210-1860 27060-30210
Specifications
Amp | 100 A |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | 10.5 mm |
Grooves | 7 qty |
Length (L.1) | 174 mm |
Measurement (A) | 97.5 mm |
Outside Diameter (O.D.1) | 58 mm |
Pivot Foot Length (B) | 60 mm |
Plug Code | PL_4000 |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
TOYOTA | Dyna 3.0 | [1KD-FTV] | 10.2009- |
TOYOTA | Dyna 3.0 D4d | [1KD-FTV] | 09.2011-05.2015 |
TOYOTA | Hiace 2.5 | [1KD-FTV] | 09.2006- |
TOYOTA | Hiace 2.5 D-4D | [2KD-FTV] | 09.2006- |
TOYOTA | Land Cruiser 3.0 | [1KD-FTV] | 01.2011- |
TOYOTA | Land Cruiser Prado 3.0 | [1KD-FTV] | 08.2009- |
TOYOTA | Land Cruiser Prado 3.0 D-4D | [1KD-FTV] | 08.2009- |
Reference Information
2040293 0986082010 27060-30060 20132522 2040293.0 CAL40225AS 556155RI 2040293.1 CAL40225 210775A CAL40225ES 20132392OE DENDAN1070 20132392BN 113969 ALN3969 24056R 2040225 27060-30130 ALTJ010 556155RID 27060-30131 57033 LRA3067 8EL011713-121 27060-30210 104210-5441 CAL40293GS 104210-5440 104210-5442 986082010 CA2069IR CAL40293OS 89215342 CAL40225GS ALTJ010U 20132522OE 27060-30080 447190 9447 DRA0246 104210-3410 104210-3411 195.574.100 LRA03067 ALT30464 195.574.100.050 20132392 20132522BN CAL40225OS CAL40293RS DAN1070 104211-8741 2040225.1 104210-1860 CAL40293 2040225.0 UD15310A 195.574.100.265 CAL40293ES 195.574.100.260 CAL40293AS 28-5679 DA1356 ANM50699X CAL40225RS 210775Video/Publications
0986082010 104210-1860 104210-3410 104210-3411 104210-5440 104210-5441 104211-8741 113969 195.574.100 20132392 20132522 2040225 2040293 210775 24056R 27060-30060 27060-30080 27060-30130 27060-30131 27060-30210 28-5679 57033 89215342 9447 ALN3969 ALT30464 ALTJ010 CA2069IR CAL40225 CAL40225AS CAL40225ES CAL40225GS CAL40225OS CAL40225RS CAL40293 CAL40293AS CAL40293ES CAL40293GS CAL40293OS CAL40293RS DA1356 DAN1070 DENDAN1070 DRA0246 LRA03067 LRA3067 UD15310AAdd Your Number
