Associated Numbers
05037198AC 0986UR6350 11013 421000-7010 5037198AC 8MR3404G 90-29-5715 UD14188ASpecifications
| Amp | 180 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 12 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.5 mm |
| Diameter (D.4) | M10x1.5 mm |
| Grooves | 7 qty |
| Length (L.1) | 172.5 mm |
| Mount Inside Length or Pad Mount C-C (C) | 67.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 52 mm |
| Plug Code | PL_2804 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 46 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DODGE | Viper 8.4 | [EWE] | 01.2008-12.2010 |
Reference Information
0986UR6350 00986UR6350 90-29-5715 A-80385 5037198AC 11013 05037198AC 421000-7010 UD14188AVideo/Publications
05037198AC 0986UR6350 11013 421000-7010 90-29-5715 A-80385 UD14188AAdd Your Number
