Associated Numbers
100211-5010 100213-0421 100213-0450 100213-0451 100213-0700 100213-0710 100213-0740 100213-0745 100213-2220 195.701.055 2040169 27040-64040 27040-64050 27040-64051 27040-64052 27060-64020 27060-64020-84 27060-64021 27060-64021-84 27060-64030 28-0975 40578RI 56443 9262 A6390S AG0322 ALT30330 CAL40169 CAL40169AS CAL40169ES CAL40169GS CAL40169OS CAL40169RS DRA3227 EAA-253305 JA578IR LRA01259 UD13588A UNIT BOM 290-168Specifications
Amp | 55 A |
Bottom Mounting Foot Width (B) | 70 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10.5 mm |
Grooves | 1 qty |
Groove Width (W.1) | 12 mm |
Length (L.1) | 209 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 45 mm |
Outside Diameter (O.D.2) | 74 mm |
Plug Code | PL_3500 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 146 mm |
Pulley Type | SOLID |
Unit Type | DENSO |
Vacuum Pump | Yes |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Corolla 1.8 D | [1C-L] | 01.1987-12.1992 |
TOYOTA | Liteace 1.8 D | [1C] | 01.1985-12.1988 |
Reference Information
100213-0421 100213-0740 27060-64030 9262 195.701.055 CAL40169ES 2T435 100213-0700 27060-64020-84 100213-0745 CAL40169AS DRA3227 ALT6126 445627 100211-5010 ALT421690 40578RI BOM 27040-64040 UNIT LRA01259 2704064150 ALT30330 CGB-13227 002-T435 ALT435 UD13588A 100213-0710 27040-64051 27040-64052 AG0322 CAL40169OS 100213-2220 27040-64050 CAL40169 JA578IR 28-0975 290-168 CAL40169GS ALTF445 CAL40169RS A6390S 27060-64021 27060-64020 2040169 100213-0450 100213-0451 LRA1259 27060-64021-84 EAA-253305 56443Video/Publications
002-T435 100211-5010 100213-0421 100213-0450 100213-0451 100213-0700 100213-0710 100213-0740 100213-0745 100213-2220 195.701.055 2040169 27040-64040 27040-64050 27040-64051 27040-64052 27060-64020 27060-64020-84 27060-64021 27060-64021-84 27060-64030 28-0975 2T435 40578RI 56443 9262 A6390S AG0322 ALT30330 ALT421690 ALT435 ALTF445 CAL40169 CAL40169AS CAL40169ES CAL40169GS CAL40169OS CAL40169RS CGB-13227 DRA3227 EAA-253305 JA578IR LRA01259 LRA1259 UD13588A UNIT BOM 290-168Add Your Number
