Associated Numbers
DAN2026 UD810110(DENSO)A 111048 CAL40550GS 1002111630 1002111680 1002114690 1012111310 55639 28-1504 ALN0551 1588164201 1624164010 1624164011 1624164012 185046430 553861RI LRA02616 115.521.040 20132055OE 2040550.1 2706087201 2706087202 2706087501 2706096001 12189N 12189R DENDAN2026Specifications
Amp | 40 A |
Bottom Mounting Foot Width (B) | 21 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10 mm |
Grooves | 1 qty |
Groove Width (W.1) | 9.5 mm |
Length (L.1) | 144 mm |
OEM Product | Yes |
Outside Diameter (O.D.1) | 38.5 mm |
Outside Diameter (O.D.2) | 63 mm |
Plug Code | PL_2500 |
Product Line | Premium Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 43 mm |
Pulley Type | SOLID |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DAIHATSU | Cuore 0.6 | ||
DAIHATSU | Cuore 0.8 | [ED10] | 09.1985-11.1996 |
DAIHATSU | Cuore 0.8 | [ED20] | 01.1995-11.1996 |
DAIHATSU | Cuore 0.8 4WD | [ED10] | 09.1986-10.1988 |
DAIHATSU | Hijet 0.8 | [CD] | 06.1986-12.1989 |
DAIHATSU | Hijet 1.0 | [CB] | 06.1986-12.1989 |
DAIHATSU | Hijet 1.0 | [CB41] | 12.1992-05.1998 |
DAIHATSU | Hijet 1.0 i | 07.1994-05.1998 | |
HUSQVARNA | PT26D | [403D-11] | 01.2008- |
JCB | CX | [403C-11] | |
KUBOTA | Engine | ||
TOYOTA | Various Models | [FGF20] | 01.1989- |
Reference Information
2706087201 DAN2026 16791-64011 185046220 16705-64011 16705-64012 101211-1310 27060-87202-000 LRA2616 02-631200 2706087202 2040550.1 5540481 1002114690 115.521.040 27060-87502-000 20132055OE CAL40550GS 12189R 2.70609E+12 02-600935 27060-87201-000 100211-4690 1012111310 62812000050 27060-87501-000 16231-64012 LRA02616 1624164012 1624164011 12189N 553861RI 1624164010 UD810110(DENSO)A 27060-87801-000 1588164201 6281-200-002-0 02/631200 100211-1630 15881-64200 28-1504 15881-64202 2706087501 DENDAN2026 ALN0551 1002111680 111048 600-821-2350 02/600935 185046430 101211-8961 100211-1680 2706096001 ALT6115 3A011-74012 1002111630 210657 55639Video/Publications
1002111630 1002111680 1002114690 1012111310 111048 115.521.040 12189N 12189R 1588164201 1624164010 1624164011 1624164012 185046430 20132055OE 2040550.1 2706087201 2706087202 2706087501 2706096001 28-1504 553861RI 55639 ALN0551 CAL40550GS DAN2026 DENDAN2026 LRA02616 LRA2616 UD810110(DENSO)A 210657Add Your Number
