Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 696.26 including GST
NZ$ 605.44 excluding GST
or four payments of $174.07
with
Learn More
each
A6348
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
104210-6120Associated Numbers
104210-6120 115720 20132344BN 20139N 20139N-OS 20139R 2040443 28-6781 553759RI 845.512.150 8X23-10300-CB A6348 AEK3641 AG1243 ALN6120 ALT30491 C2Z3415 CAL40443 CAL40443AS CAL40443ES CAL40443GS CAL40443OS CAL40443RS DRA0964 EAA-223454 LRA03641 RAA11075 UD12118A AS-PLList AS-PL AUTOELECTRO CARGO CASCO DELCO DENSOList EAA ELSTOCK FORDList GHIBAUDI JAGUAR KRAUF KUHNER LUCAS PSH REAL SANDO WAI / TRANSPO WOODAUTO anj305 658528 1042106120 Denso 1042106120OR +line Cargo 12090622 EuroTec 286781 Elstock 845512150 8X2310300CB Ford 8x2310300cb 930964 EDR Jaguar Remy Lucas TNA108 TWA FORD 8X2310300CC C2Z1140 C2Z18797 C2Z31670 C2D2661Specifications
| Amp | 150 A |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 12 mm |
| Diameter (D.3) | 13 mm |
| Length (L.1) | 198 mm |
| Mount Inside Length or Pad Mount C-C (C) | 47 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 40 mm |
| Pad mount thickness (E.2) | 50 mm |
| Pad mount thickness (E.3) | 50 mm |
| Plug Code | PL_2305 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 57.50 mm |
| Pulley to Mount Distance (A) | 23 mm |
| Pulley Type | Clutch |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JAGUAR | XF 2.2 D | [224DT] | 03.2012-04.2015 |
| JAGUAR | XF 2.2 D | [224DT] | 04.2011-04.2015 |
| JAGUAR | XF 2.2 D | [224DT] | 05.2011-04.2015 |
| JAGUAR | XF 2.7 D | [AJD] | 03.2008-04.2015 |
| JAGUAR | XF 3.0 D | [306DT] | 03.2009-04.2015 |
| JAGUAR | XF 3.0 D | [AJV6D] | 03.2009-04.2015 |
| JAGUAR | XF Sportbrake 2.2 D | [224DT] | 09.2012-04.2014 |
| JAGUAR | XF Sportbrake 3.0 D | [306DT] | 09.2012- |
| JAGUAR | XF Sportbrake 3.0 D | [AJV6D] | 09.2012- |
| JAGUAR | XJ 3.0 D | [AJV6D] | 10.2009-12.2015 |
Reference Information
| 104210-6120 | DENSO |
| 115720 | CARGO |
| 20132344BN | REAL |
| 20139N | WAI / TRANSPO |
| 20139N-OS | WAI / TRANSPO |
| 20139R | WAI / TRANSPO |
| 2040443.0 | SANDO |
| 28-6781 | ELSTOCK |
| 442164 | LOGISTIK |
| 553759RI | KUHNER |
| 845.512.150.050 | PSH |
| 845.512.150.058 | PSH |
| 89215930 | POWERMAX |
| 8EL015630-731 | HELLA |
| 8X23-10300-CB | FORD |
| 8X23-10300-CC | FORD |
| A135.942 | PSH |
| A6348 | AS-PL |
| AEK3641 | AUTOELECTRO |
| AG1243 | GHIBAUDI |
| ALN6120 | KRAUF |
| ALT30491 | WOODAUTO |
| ALT604 | ROLLCO |
| ALT604CP | ROLLCO |
| ALT6827 | ELECTROLOG |
| ALTS458 | 3EFFE |
| C2D59620 | JAGUAR |
| C2Z1140 | JAGUAR |
| C2Z18797 | JAGUAR |
| C2Z31670 | JAGUAR |
| C2Z3415 | JAGUAR |
| CAL40443AS | CASCO |
| CGB-10964 | AINDE |
| DRA0964 | DELCO |
| F032115720 | CARGO |
| LRA03641 | LUCAS |
| LRA3641 | LUCAS |
| PRAS458 | 3EFFE |
| RAA11075 | DELCO |
| RNL104210-6120 | RNL |
| STX110370 | STARDAX |
| STX110370R | STARDAX |
| UD12118A | AS-PL |
Video/Publications
