Associated Numbers
104210-5890 11390R 12870 20132833BN 2040338 31100-R40-A01 553935RI 90-29-5722 94812 A-80395 CAL40338AS CSF89 DRA0927 UD11508A
DXA567 65-8519 ANJ295
Specifications
| Amp | 130 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | M10x1.25 mm |
| Grooves | 7 qty |
| Length (L.1) | 175 mm |
| Mount Inside Length or Pad Mount C-C (C) | 35 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 60 mm |
| Plug Code | PL_4001 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 43 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ACURA | TSX 2.4 | 01.2009- | |
| HONDA | Accord 2.4 | 01.2008- |
Reference Information
11390R 90-29-5722 A-80395 CSF89 06311R40505RM 94812 CAL40338AS UD11508A 116658 2040338 31100-R40-A01 20132833BN 104210-5890 A6300 553935RI ALT6399 12870 DRA0927Video/Publications
104210-5890 11390R 12870 20132833BN 2040338 31100-R40-A01 553935RI 90-29-5722 94812 A-80395 CAL40338AS CSF89 DRA0927 UD11508AAdd Your Number
