Associated Numbers
104210-2140 104210-2141 104210-5510 104210-5511 104210-5512 104210-5513 104210-5514 104210-5515 11325R 11326R 12865 27060-0P240 27060-0P241 27060-31161 27060-31162 554085RI 90-29-5705 94757 A-80345 A-80390 ALN0122 UD11466A UD11506A 104210-5530 1042102140 1042102141 1042102142Specifications
Amp | 150 A |
Bottom Mounting Foot Width (B) | 20 mm |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 11 mm |
Diameter (D.3) | M10x1.25 mm |
Diameter (D.4) | M8x1.25 mm |
Grooves | 7 qty |
Length (L.1) | 165 mm |
Mount Inside Length or Pad Mount C-C (C) | 35 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 52.5 mm |
Plug Code | PL_4000 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 35 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LEXUS | ES350 3.5 | 01.2013-12.2014 | |
LEXUS | ES 350 3.5 V6 | 01.2013- | |
LEXUS | RX 350 3.5 | 01.2010-12.2013 | |
LEXUS | RX 350 3.5 V6 | 01.2010- | |
TOYOTA | Highlander 3.5 | 01.2008-12.2015 | |
TOYOTA | Highlander 3.5 V6 | 01.2008- | |
TOYOTA | RAV4 3.5 | 01.2009-12.2012 | |
TOYOTA | RAV4 3.5 V6 | 01.2009- | |
TOYOTA | Sienna 3.5 | 01.2007-12.2015 | |
TOYOTA | Sienna 3.5 V6 | 01.2007- | |
TOYOTA | Venza 3.5 | [2GR-FE] | 01.2009-12.2015 |
TOYOTA | Venza 3.5 V6 | 01.2010- |
Reference Information
UD11506A CAL40515AS 27060-0P241 27060-0P240 ALN0122 104210-5511 104210-5510 104210-5513 104210-5512 104210-5515 2040515 104210-5514 554085RI 104210-2140 104210-2141 A-80345 11325R 94757 90-29-5705 27060-31162 27060-31161 UD11466A 20132515BN A-80390 A6298 12865 11326RVideo/Publications
104210-2140 104210-2141 104210-5510 104210-5511 104210-5512 104210-5513 104210-5514 104210-5515 11325R 11326R 12865 27060-0P240 27060-0P241 27060-31161 27060-31162 554085RI 90-29-5705 94757 A-80345 A-80390 ALN0122 UD11466A UD11506AAdd Your Number
