Associated Numbers
063377560010 0986083070 104210-3560 104210-4640 104210-5740 11054R 114810 2040274 209396 28-5548 301966RI 301966RID 30659346 30659369 30667103 30737529 36001463 3M5T-10300-SC 3M5T-10300-SD 57459 815.527.150 8603496 90-29-5745 9464 AEK2934 ALN5910 ALT30371 CAL40274 CAL40274AS CAL40274ES CAL40274GS CAL40274OS CAL40274RS DAN1059 DENDAN1059 LRA02934 LRA2934 MAN7560 UD804927(DENSO)ASpecifications
Amp | 150 A |
Bottom Mounting Foot Width (B) | 38.2 mm |
Diameter (D.1) | 8 mm |
Diameter (D.2) | 8.5 mm |
Diameter (D.3) | 9.5 mm |
Grooves | 5 qty |
Length (L.1) | 169.5 mm |
Mount Inside Length or Pad Mount C-C (C) | 90 mm |
OEM Product | Yes |
Outside Diameter (O.D.1) | 55 mm |
Pad mount thickness (E.1) | 38 mm |
Pad mount thickness (E.2) | 33 mm |
Pad mount thickness (E.3) | 33 mm |
Plug Code | PL_3413 |
Product Line | Premium Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 35 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VOLVO | C70 2.4 | [B5244S5] | 03.2006-10.2009 |
VOLVO | C70 2.4 i | [B5244S4] | 03.2006-10.2009 |
VOLVO | C70 T5 | [B5254T3] | 03.2006-02.2007 |
VOLVO | S40 2.4 | [B5244S4] | 01.2004-12.2010 |
VOLVO | S40 2.4 | [B5244S5] | 01.2004-12.2010 |
VOLVO | S40 T5 | [B5254T3] | 01.2004-12.2007 |
VOLVO | S40 T5 AWD | [B5254T3] | 04.2004-12.2007 |
VOLVO | V50 2.4 | [B5244S4] | 04.2004-12.2010 |
VOLVO | V50 2.4 | [B5244S5] | 04.2004-12.2010 |
VOLVO | V50 T5 | [B5254T3] | 04.2004-12.2007 |
VOLVO | V50 T5 AWD | [B5254T3] | 04.2004-12.2007 |
Reference Information
DAN1059 LRA02934 9464 30667103 2040274 30659346 301966RID UD804927(DENSO)A 30659369 442122 8603496 ALN5910 986083070 LRA2934 28-5548 36001463 30737529 3M5T-10300-SC 104210-4640 815.527.150 3M5T-10300-SD ALT6268 301966RI MAN7560 CAL40274RS 90-29-5745 30795134 CAL40274 DENDAN1059 209396 AEK2934 11054R ALT30371 CAL40274GS CAL40274ES 114810 0986083070 CAL40274AS 63377560010 CAL40274OS 57459 104210-3560 104210-5740 ALT6138Video/Publications
063377560010 0986083070 104210-3560 104210-4640 104210-5740 11054R 114810 2040274 209396 28-5548 301966RI 301966RID 30659346 30659369 30667103 30737529 36001463 3M5T-10300-SC 3M5T-10300-SD 57459 815.527.150 8603496 90-29-5745 9464 AEK2934 ALN5910 ALT30371 CAL40274 CAL40274AS CAL40274ES CAL40274GS CAL40274OS CAL40274RS DAN1059 DENDAN1059 LRA02934 LRA2934 MAN7560 UD804927(DENSO)AAdd Your Number
