Associated Numbers
063377434 063377434010 102211-2120 102211-2250 11.1792 11.1792M 114186 13957N 13957RW 13959N 20132453BN 20132453OE 2040354 27060-28110 27060-28120 28-4679 401792RI 57185 8EL738211-751 9213381 9324 AEK2210 ALT30349 CAL40354AS CAL40354GS DRA4274 EAA-222113 JA1792IR LRA02210Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 18 mm |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | M8x1.25 mm |
| Diameter (D.3) | M10x1.25 mm |
| Grooves | 7 qty |
| Length (L.1) | 171 mm |
| Mount Inside Length or Pad Mount C-C (C) | 45.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 55 mm |
| Plug Code | PL_3314 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 70 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | RAV4 2.0 4WD | [1AZ-FE] | 06.2006- |
| TOYOTA | RAV4 2.0 i | [1AZ-FE] | 01.2000- |
Reference Information
ALT6092 11.1792 209384 9324 57185 2040354 LRA02210 102211-2250 9213381 DRA4274 ALT30349 28-4679 CAL40354GS A6102 27060-28110 JA1792IR 401792RI 11.1792M ANM36494X 63377434 2.70603E+11 CAL40354AS ALTE435 20132453BN 8EL738211-751 LRA2210 27060-28110-84 13957RW 27060-28170 63377434010 AEK2210 27060-0H010 102211-2120 114186 446007 13957N EAA-222113 27060-28120 20132453OEVideo/Publications
063377434 063377434010 102211-2120 102211-2250 11.1792 11.1792M 114186 13957N 13957RW 20132453BN 20132453OE 2040354 27060-28110 27060-28120 28-4679 401792RI 57185 8EL738211-751 9213381 9324 AEK2210 ALT30349 ALTE435 CAL40354AS CAL40354GS DRA4274 EAA-222113 JA1792IR LRA02210 LRA2210 209384Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Alternators.
