Associated Numbers
101210-0950 101210-0951 101210-09513E 1204426 13222934 13256933 24063R 28-5676 301955RI 301955RIM 32118960 6204257 63377423 AEK3065 ALT30197 CA1955IR DAN583 EAA-222252 LRA03064 MAN7423Specifications
Amp | 70 A |
Bottom Mounting Foot Width (B) | 64 mm |
Diameter (D.1) | 9 mm |
Diameter (D.2) | 9 mm |
Diameter (D.3) | 9 mm |
Grooves | 6 qty |
Length (L.1) | 193.5 mm |
Mount Inside Length or Pad Mount C-C (C) | 55 mm |
OEM Product | Yes |
Outside Diameter (O.D.1) | 54 mm |
Pad mount thickness (E.1) | 64 mm |
Pad mount thickness (E.2) | 64 mm |
Pad mount thickness (E.3) | 64 mm |
Plug Code | PL_2200 |
Product Line | Premium Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 45 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
OPEL | Agila 1.3 CDTi | [Z13DT] | 08.2003- |
OPEL | Agila 1.3 CDTi | [Z13DTJ] | 05.2008- |
OPEL | Astra H 1.3 CDTi | [Z13DTH] | 08.2005- |
OPEL | Corsa C 1.3 CDTi | [Z13DT] | 07.2003- |
OPEL | Corsa C 1.3 CDTi 16V | [Z13DT] | 08.2005- |
OPEL | Corsa D 1.3 CDTi | [Z13DTH] | 08.2006- |
OPEL | Corsa D 1.3 CDTi | [Z13DTJ] | 08.2006- |
OPEL | Meriva 1.3 CDTi | [Z13DT] | 04.2005-05.2010 |
OPEL | Tigra 1.3 CDTi | [Z13DT] | 06.2004- |
VAUXHALL | Agila 1.3 CDTi | [Z13DTJ] | 01.2008- |
VAUXHALL | Corsa 1.3 CDTi 16V | [Z13DTH] | 07.2006- |
VAUXHALL | Corsa 1.3 CDTi 16V | [Z13DTJ] | 07.2006- |
Reference Information
24063R 13256933 301955RIM 24063N 13256930 95520872 6204257 ALT6247 MAN7423 135.556.070.050 DAN583 LRA3064 4861 114895 443084 6204664 1204432 0986081070 CAL30206AS 63377423 ALTL798 EAA-222252 89213627 20104602OE LRA03064 20104602BN 95519869 1204426 986081070 1204429 8EL011712-541 PRAL798 13222934 ALT30197 9.4332E+11 ALT363CP CA1955IR 2030206.1 6204281 57454 101210-09513E CAL30206GS 2030206 101210-0950 101210-0951 135.556.070.260 210734 301955RI 28-5676Video/Publications
101210-0950 101210-0951 101210-09513E 1204426 13222934 13256933 24063R 28-5676 301955RI 301955RIM 32118960 6204257 63377423 AEK3065 ALT30197 CA1955IR DAN583 EAA-222252 LRA03064 LRA3064 MAN7423 210734 PRAL798 ALTL798 0986081070 135.556.070.050 135.556.070.260 CAL30206AS CAL30206GS 20104602OE 20104602BN 4861 57454 114895 8EL011712-541 943319551010 89213627 2030206.0 2030206.1 443084 24063NAdd Your Number
