Associated Numbers
0986043061 101211-0580 101211-0581 101211-0582 101211-5720 11.1369 111537 13537N 20110265 27060-76070 27060-76080 28-2714 401369RI 8EL737569-001 9090246 9212221 AEA2265 ALT30021 DRA3515 JA1369IR LRB00265 SA910Specifications
| Amp | 70 A |
| Bottom Mounting Foot Width (B) | 58 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 10 mm |
| Grooves | 6 qty |
| Length (L.1) | 166 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 55 mm |
| Plug Code | PL_3314 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 90 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Previa 2.4 | [2TZ-FE] | 08.1993-12.1999 |
| TOYOTA | Previa 2.4 4WD | [2TZ-FE] | 08.1993- |
| TOYOTA | Previa 2.4 DLX | [2TZ-FE] | 01.1994-01.1995 |
| TOYOTA | Previa 2.4 GX | (TCR1_, 2_)[2TZ-FZE] | 01.1994-07.1997 |
| TOYOTA | Previa 2.4 GX | (TCR1_,2_)[2TZ-FZE] | 01.1994-07.1997 |
Reference Information
8EL737569-001 AEA2265 ANM35735X LRB00265 ALT30021 101211-5720 111537 20132800BN 101211-0582 0986043061 20110265 101211-0580 JA1369IR 101211-0581 28-2714 CAL40008AS 27060-76070 9090246 ALTW204 LRB265 9212221 446653 2040008 13537N 401369RI DRA3515 SA910 ALT6299 11.1369 27060-76080 986043061Video/Publications
0986043061 101211-0580 101211-0581 101211-0582 101211-5720 11.1369 111537 13537N 20110265 27060-76070 27060-76080 28-2714 401369RI 8EL737569-001 9090246 9212221 AEA2265 ALT30021 ALTW204 DRA3515 JA1369IR LRB00265 LRB265 SA910Add Your Number
