Associated Numbers
104210-5470 104210-5471 20132683BN 2040386 27060-51010 A6008 CAL40386ASSpecifications
Amp | 120 A |
Diameter (D.1) | 9 mm |
Diameter (D.2) | 9 mm |
Diameter (D.3) | 10 mm |
Diameter (D.4) | 10 mm |
Grooves | 9 qty |
Length (L.1) | 168 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 60.5 mm |
Pad mount thickness (E.1) | 60 mm |
Pad mount thickness (E.2) | 60 mm |
Pad mount thickness (E.3) | 60 mm |
Pad mount thickness (E.4) | 60 mm |
Pivot Inside Length (C) | 64 mm |
Plug Code | PL_4000 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Type | SOLID |
Pulley to Mount Distance (A) | 22 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Land Cruiser 4.5 V8 |
Reference Information
104210-5470 20132683BN 104210-5471 2040386 27060-51010 A6008 CAL40386ASVideo/Publications
