Associated Numbers
0986038211 14436 14436N 14436R 14947 155.506.075 20100707 2032119 210804 28-2904 37300-24510 37300-24511 37300-32510 37300-32511 37300-32520 37300-32530 40115RIR 40689RI 40690RI 56461 90-27-3084 90-27-3084N 9212793 943346088010 A-8209 A002T09493 A002T14792 A002T14792ZC A002T49992 A2T09493 A2T14792 A2T14792ZC A2T49992 AB175002 AB175015 AB175051 AB175053 AEA1252 AG0381 ALT10019 AR175AA CAL32119 CAL32119AS CAL32119ES CAL32119GS CAL32119OS CAL32119RS DRA3148 JA690IR LRA02726 MD102084 MD114620 TA000A13201 TA000A15101 UD12287ASpecifications
| Amp | 75 A |
| Bottom Mounting Foot Width (B) | 13.5 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | 8.5 mm |
| Grooves | 4 qty |
| Length (L.1) | 161 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 55 mm |
| Plug Code | PL_2004 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 37 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | Excel 1.5 | 01.1991-12.1991 | |
| HYUNDAI | Sonata 1.8 i | [4G62] | 01.1988-12.1993 |
| HYUNDAI | Sonata 2.0 i | [G4CP] | 01.1988-12.1993 |
| HYUNDAI | Sonata 2.4 | 01.1989-12.1989 | |
| HYUNDAI | Sonata 2.4 i | 01.1983-12.1991 | |
| MITSUBISHI | Colt 1.2 | 09.1986-04.1988 | |
| MITSUBISHI | Colt 1.3 i | ||
| MITSUBISHI | Colt 1.5 i | 01.1990- | |
| MITSUBISHI | Galant 2.0 | 01.1980- | |
| MITSUBISHI | Galant 2.4 i | 01.1988- | |
| MITSUBISHI | Lancer 1.2 | 01.1984-10.1986 | |
| MITSUBISHI | Lancer 1.5 | 06.1985-04.1988 |
Reference Information
ALT8790 0986038211 A002T14792ZC MD125569 002-C323 155.506.075 ALC323 A002T14792 9212793 40690RI AG0381 A002T49977 MD102084 ALT371390 40689RI TA000A13201 TA000A15101 40115RIR CGB-13143 37300-32511 DRA3148 A002T49972 CAL32119 A2T09493 A2T49992 2032119 90-27-3084N 37300-32510 2C323 AB175002 A002T09493 MD106713 14436N A002T49922 ALTJ450 56461 28-2904 37300-24511 37300-24510 14436R AR175AA 14947 CAL32119GS 986038211 445738 LRA2726 445739 37300-32520 AB175051 CAL32119OS ALTF536 ALT6150 UD12287A 90-27-3084 AB175015 A2T49977 AB175053 AEA1252 CAL32119RS A2T14792 210804 A002T49992 9.43346E+11 JA690IR 20100707 ALT10019 37300-32530 14436 ALT341190 ALT6140 A2T49972 LRA02726 A2T49922 A2T14792ZC 3730032521 A-8209 CAL32119ES CAL32119AS MD114620Video/Publications
002-C323 0986038211 14436 14436N 14436R 14947 155.506.075 20100707 2032119 210804 28-2904 2C323 37300-24510 37300-24511 37300-32510 37300-32511 37300-32520 37300-32530 40115RIR 40689RI 40690RI 56461 90-27-3084 90-27-3084N 9212793 943346088010 A-8209 A002T09493 A002T14792 A002T14792ZC A002T49992 A2T09493 A2T14792 A2T14792ZC A2T49992 AB175002 AB175015 AB175051 AB175053 AEA1252 AG0381 ALC323 ALT10019 ALT341190 ALT371390 ALT6140 ALT6150 ALTF536 ALTJ450 AR175AA CAL32119 CAL32119AS CAL32119ES CAL32119GS CAL32119OS CAL32119RS CGB-13143 DRA3148 JA690IR LRA02726 LRA2726 MD102084 MD114620 TA000A13201 TA000A15101 UD12287AAdd Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Alternators.
