Associated Numbers
11083 11579N 175.514.130 2035326 23700-AA700 23700-AA701 554388RI 554388RIM 554447RI 90-27-3431 A002TL0091 A002TL0091A A002TL0091AM A2TL0091 A2TL0091A A2TL0091AM CAL35326 CAL35326AS CAL35326ES CAL35326GS CAL35326OS CAL35326RS DRA1253 MITA2TL0091 UD12489A AS-PL CASCO DELCO KUHNER MITSUBISHI PSH SANDO SUBARU WAI / TRANSPO WILSON WOODAUTO 0986UR6098 Bosch ruil 11579 STEMOT 12061124 EuroTec 175514130 23700AA700 Subaru 23700AA701 931253 EDR Mitsubishi Remy 23700AA770 a2tx3291
23700AA710 A2TL0091 A2tL0091A 23700aa700
Specifications
| Amp | 110 A |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 10.5 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 157 mm |
| Outside Diameter (O.D.1) | 55 mm |
| Pad mount thickness (E.1) | 40 mm |
| Pad mount thickness (E.2) | 40 mm |
| Pivot Foot Length (B) | 40.4 mm |
| Pivot Inside Length (C) | 55 mm |
| Plug Code | PL_3308 |
| Pulley Type | SOLID |
| Pulley to Mount Distance (A) | 32 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUBARU | Forester 2.0 AWD | [EE20Z] | 01.2009- |
| SUBARU | Forester 2.0 AWD | [EJ20] | 01.2008- |
| SUBARU | Forester 2.0 AWD | [FB20] | 01.2010- |
| SUBARU | Forester 2.5 AWD | [EJ25] | 09.2008- |
Reference Information
23700-AA700 23700-AA701 11083 209445 A002TL0091AM CAL35326RS 2035326 A2TL0091A CAL35326 A002TL0091A 11579N A2TL0091 554447RI A002TL0091 MITA2TL0091 A2TL0091AM CAL35326OS 175.514.130 CAL35326ES DRA1253 554388RIM CAL35326GS 90-27-3431 554388RI UD12489A CAL35326ASVideo/Publications
11083 11579N 175.514.130 2035326 23700-AA700 23700-AA701 554388RI 554388RIM 554447RI 90-27-3431 A002TL0091 A002TL0091A A002TL0091AM A2TL0091 A2TL0091A A2TL0091AM CAL35326 CAL35326AS CAL35326ES CAL35326GS CAL35326OS CAL35326RS DRA1253 MITA2TL0091 UD12489A 209445< Critical Notes >
Users with our AD100 / AD100+ can test this alternator 'C' terminal by using the green wire on the tester and selecting the P-D Function, Although primarily used for the dedicated P-D MAZDA alternators the pulse width/Frequency is the same on this particular regulator
