Associated Numbers
11145 31100-5A2-A02 31100-5A2-A02RM 31100-5A2-AA000M2 90-27-3440 A-80587 A005TL0581 A005TL0581ZC A5TL0581 A5TL0581ZC AHGA88 UD11073A UNIT BOM 203-677Specifications
Amp | 110 A |
Bottom Mounting Foot Width (B) | 20 mm |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | M10x1.25 mm |
Grooves | 7 qty |
Length (L.1) | 183 mm |
Mount Inside Length or Pad Mount C-C (C) | 43.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 57.5 mm |
Plug Code | PL_1000 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 44 mm |
Pulley Type | CLUTCH |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | Accord 2.4 | 01.2013-12.2014 |
Reference Information
BOM AHGA88 UNIT A005TL0581ZC 31100-5A2-A02RM 90-27-3440 A5TL0581ZC A005TL0581 UD11073A 31100-5A2-A02 A5TL0581 A-80587 203-677 11145 31100-5A2-AA000M2Video/Publications
11145 31100-5A2-A02 31100-5A2-A02RM 31100-5A2-AA000M2 90-27-3440 A-80587 A005TL0581 A005TL0581ZC A5TL0581 A5TL0581ZC AHGA88 UD11073A UNIT BOM 203-677Add Your Number
