Associated Numbers
11183 A-80664 A2TX3381 UD11076A 0986CR6259 Bosch ruil 11683 Lester 11869 175521130 PSH 2331331302 DRI 23700AA760 Subaru 287879 Elstock 288553 A002TX3381 Mitsubishi show A002TX5081 A002TX5081A A2TX5081 A2TX5081A AL4319X (USA) LRA04270 Lucas LRA04444
ARROWHEAD 400-48212, 400-48212R
LESTER 11683
MITSUBISHI A002TX3381, A002TX3381A,
ARROWHEAD 400-48212, 400-48212R
LESTER 11683
MITSUBISHI A002TX3381, A002TX3381A, A2TX3381, A2TX3381A
SUBARU 23700AA760, 23700AA761
WAI New 11683N
Alltech 324-11683
Armature G Roy 11683
EGI A-11683
Lester 11683
Mitsubishi A002TX3381, A002TX3381A
Mitsubishi Sales A2TX3381, A2TX3381A
Our Part Number 11683N
Part # 11683
Power Select 11683N
Powerite Automotive 11683
Raw Power 11683N
Road Warrior 11683N
Subaru 23700-AA760, 23700-AA761
Techno CVC IMP-A11683
Zorko 11683
A2TX3381, A2TX3381A
SUBARU 23700AA760, 23700AA761
Specifications
| Amp | 130 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 181 mm |
| Mount Inside Length or Pad Mount C-C (C) | 79.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 56 mm |
| Plug Code | PL_3401 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 38.5 mm |
| Pulley Type | CLUTCH |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUBARU | Forester 2.0 | 01.2014- | |
| SUBARU | Forester 2.5 | 01.2014- |
