Associated Numbers
13648N 31100-P0G-A02 31100-P0G-A03 9214086 A3TJ0491 AHGA62 UD11041A
31100RKB004
Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 46 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 10.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 171 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 65 mm |
| Plug Code | PL_4001 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 83.5 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HONDA | Elysion 3.0 | [J30A] | 07.2005- |
Reference Information
UD11041A 9214086 13648N 31100-P0G-A02 31100-P0G-A03 A3TJ0491 AHGA62Video/Publications
13648N 31100-P0G-A02 31100-P0G-A03 9214086 A3TJ0491 AHGA62 UD11041AAdd Your Number
