Associated Numbers
12774 90-27-3341 A-80236 A003TG1581 A3TG1581 A5172 ALT31263 UD11272A
A3TG4081 Mitsubishi, Alternator, 12V
A3TG4181 Mitsubishi, Alternator, 12V
A3TG4191 Mitsubishi, Alternator, 12V
Specifications
| Amp | 140 A |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 196 mm |
| Outside Diameter (O.D.1) | 57 mm |
| Pivot Foot Length (B) | 51 mm |
| Plug Code | PL_2200 |
| Pulley Type | CLUTCH |
| Pulley to Mount Distance (A) | 72 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| PONTIAC | GTO 6.0 V8 | 01.2005- |
Reference Information
UD11272A A3TG1581 A5172 A003TG1581 90-27-3341 12774 ALT31263 A-80236Video/Publications
12774 90-27-3341 A-80236 A003TG1581 A3TG1581 A5172 ALT31263 UD11272AAdd Your Number
