Associated Numbers
12316N 90-27-3205 A-80069 A4T66786 ALT31259 DRA0327 ME150143 UD11282A UNITBOM203-282Specifications
Amp | 50 A |
Bottom Mounting Foot Width (B) | 13.5 mm |
Diameter (D.1) | M12x1.25 mm |
Diameter (D.2) | 12.5 mm |
Diameter (D.3) | 12.5 mm |
Groove Width (W.1) | 21 mm |
Grooves | 1 qty |
Length (L.1) | 213 mm |
Mount Inside Length or Pad Mount C-C (C) | 81 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 59 mm |
Outside Diameter (O.D.2) | 99 mm |
Plug Code | PL_3504 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Type | SOLID |
Pulley to Mount Distance (A) | 50 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | 320 L | [3116] | 01.1992-12.1998 |
MITSUBISHI | Engine | [6D22T] | |
MITSUBISHI | Engine | [6D22] | |
MITSUBISHI | Engine 11.0 | [6D22] |
Reference Information
12316N ANM32547X DRA0327 A-80069 UNITBOM203-282 UD11282A ME150143 A4T66786 ALT31259 90-27-3205Video/Publications
12316N 90-27-3205 A-80069 A4T66786 ALT31259 DRA0327 ME150143 UD11282A UNITBOM203-282Add Your Number
