Associated Numbers
11173N 595.593.150 6E5T-10300-BA 6E5T-10300-BD 6E5T-BA 6E5T-BD 6E5T10300BA 6E5T10300BD 6E5Z-10346-BA 6E5Z10346BA 7E5T-10300-BA 7E5T-10300-BB 7E5T-BA 7E5T-BB 7E5T10300BA 7E5T10300BB 90-27-3348 90-27-3348N A-80246 A003TJ0991 A003TJ0991ZC A3TJ0991 A3TJ0991ZC GL-669 UD11032ASpecifications
| Amp | 150 A |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 12.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 154 mm |
| Mount Inside Length or Pad Mount C-C (C) | 74 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 60 mm |
| Pad mount thickness (E.1) | 75 mm |
| Pad mount thickness (E.2) | 75 mm |
| Pad mount thickness (E.3) | 75 mm |
| Plug Code | PL_3402 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 27 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Fusion 3.0 V6 | 01.2006-12.2009 | |
| LINCOLN | Zephyr 3.0 V6 | 01.2006- | |
| MERCURY | Milan 3.0 V6 | 01.2006-12.2009 |
Reference Information
6E5T-BD 90-27-3348N A3TJ0991ZC 7E5T-10300-BA 7E5T-10300-BB 6E5T-10300-BA 6E5T10300BA UD11032A 7E5T-BA A-80246 6E5T10300BD 6E5Z10346BA 90-27-3348 6E5T-10300-BD A3TJ0991 11173N 7E5T-BB ALTF906 A003TJ0991ZC ALT5444 6E5Z-10346-BA 595.593.150 A003TJ0991 7E5T10300BA 7E5T10300BB GL-669 6E5T-BAVideo/Publications
11173N 595.593.150 6E5T-10300-BA 6E5T-10300-BD 6E5T-BA 6E5T-BD 6E5T10300BA 6E5T10300BD 6E5Z-10346-BA 6E5Z10346BA 7E5T-10300-BA 7E5T-10300-BB 7E5T-BA 7E5T-BB 7E5T10300BA 7E5T10300BB 90-27-3348 90-27-3348N A-80246 A003TJ0991 A003TJ0991ZC A3TJ0991 A3TJ0991ZC ALTF906 GL-669 UD11032AAdd Your Number
