Associated Numbers
20137956OE 2035659 48-0697 5001847425 5010306537 553130RI 576.506.040 A002TA8191 A002TA8191ZT A2TA8191 A2TA8191ZT ALT31206 CAL35659 CAL35659AS CAL35659ES CAL35659GS CAL35659OS CAL35659RS DRA0847 LRB00141 UD30017ASpecifications
Amp | 40 A |
Bottom Mounting Foot Width (B) | 27 mm |
Diameter (D.1) | 8.5 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | 10.5 mm |
Grooves | 2 qty |
Groove Width (W.1) | 11 mm |
Length (L.1) | 185 mm |
Mount Inside Length or Pad Mount C-C (C) | 66 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 60 mm |
Outside Diameter (O.D.2) | 84 mm |
Plug Code | PL_9105 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 49 mm |
Pulley Type | SOLID |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
RENAULT V.I. | 135.08 4.1 | [MIDR04.02.26A/4] | 01.2000- |
RENAULT V.I. | 135.09 4.1 | [MIDR04.02.26A/4] | 01.2000- |
RENAULT V.I. | 135.10 4.1 | [MIDR04.02.26A/4] | 01.2000- |
RENAULT V.I. | 150.08 4.1 | [MIDR04.02.26B/4] | 01.2000- |
RENAULT V.I. | 150.09 4.1 | [MIDR04.02.26B/4] | 01.2000- |
RENAULT V.I. | 150.10 4.1 | [MIDR04.02.26B/4] | 01.2000- |
RENAULT V.I. | 210.15 6.2 | [MIDR06.02.26W/4] | 01.2000- |
RENAULT V.I. | S 135.09 4.1 | [MIDR04.02.26A/41] | 05.1996-01.2000 |
RENAULT V.I. | S 150.09 4.1 | [MIDR04.02.26B/41] | 05.1996-01.2000 |
RENAULT V.I. | S 210.08 6.2 | [MIDR06.02.26W] | 04.1995-01.2000 |
RENAULT V.I. | S 210.08 6.2 | [MIDR06.02.26W/41] | 04.1995-01.2000 |
RENAULT V.I. | S 210.09 6.2 | [MIDR06.02.26W] | 04.1995-01.2000 |
RENAULT V.I. | S 210.09 6.2 | [MIDR06.02.26W/41] | 04.1995-01.2000 |
Reference Information
DRA0847 20137956OE 553130RI 2035659.1 ALTS093 PRAS093 A2TA8191AM 210903 A5112 A002TA8191ZT PRAL436 MITA2TA8191 5001847425 A002TA8191 75715 CAL35659GS A2TA8191 5010306537 A002TA8191AM ALM8191 ALT376150 ALT376590 DA1957 ALT5329 115454 576.506.040 5001014157 UD30017A ALTL436 A2TA8191ZT ALTL436RRVideo/Publications
115454 20137956OE 2035659.1 5001014157 5001847425 5010306537 553130RI 576.506.040 75715 A002TA8191 A002TA8191ZT A2TA8191 A2TA8191ZT ALM8191 ALT376150 ALT376590 ALTL436 ALTL436RR ALTS093 CAL35659GS DA1957 DRA0847 MITA2TA8191 PRAL436 PRAS093 UD30017A 210903Add Your Number
