Associated Numbers
11.1513 28-2812 401513RI 8EL737736-001 9051345 9212545 A2TA1099 A2TA1099A AEB1513 JA1513IR LRA01633 WL11-18-300 WL11-18-300ASpecifications
| Amp | 80 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | 10.5 mm |
| Grooves | 2 qty |
| Groove Width (W.1) | 10 mm |
| Length (L.1) | 178 mm |
| Mount Inside Length or Pad Mount C-C (C) | 65 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 54 mm |
| Outside Diameter (O.D.2) | 80 mm |
| Plug Code | PL_2004 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 42 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MAZDA | MPV 2.5 TD | [WLT] | 05.1996-09.1999 |
Reference Information
A002TA1099A ALT5182 A002TB1298 RFIS-18-300 AEB1513 RF1S18300 LR190-731 A2TB1298 20137701OE 9051345 JA1513IR WL11-18-300A WL01-18-300 A002TA1099 A2TB1298AM 20137701BN CAL35107AS 28-2812 ALT6500 11.1513 A2TA1099 WL11-18-300 CAL35107GS 2035107 9212545 8EL737736-001 LRA01633 113785 LR190-731B LRA1633 A2TB1299 RF1S-18-300 2035107.1 210531 A002TB1299 LR190731 A002TB1298AM 401513RI A2TA1099AVideo/Publications
11.1513 113785 28-2812 401513RI 8EL737736-001 9051345 9212545 A2TA1099 A2TA1099A AEB1513 ALT6500 JA1513IR LRA01633 LRA1633 WL11-18-300 WL11-18-300A 210531Add Your Number
