Associated Numbers
0986046361 11.0983 11.0983M 111491 20130141 20193431OE 2032134 28-1808 40983RI 40983RIM 437147 56295 8EL737058-001 9020 9213035 A3T00599 A3T05499 AEB1419 ALT31052 CAL32134GS DRA3377 EAA-221436 JA983IR LRA01383 MD111932 MD141119 SA830 SB123Specifications
Amp | 75 A |
Bottom Mounting Foot Width (B) | 13 mm |
Diameter (D.1) | 8.5 mm |
Diameter (D.2) | M8x1.25 mm |
Diameter (D.3) | 8.5 mm |
Groove Width (W.1) | 10 mm |
Grooves | 2 qty |
Length (L.1) | 238 mm |
Mount Inside Length or Pad Mount C-C (C) | 55 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 58 mm |
Outside Diameter (O.D.2) | 82 mm |
Plug Code | PL_2004 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Type | SOLID |
Pulley to Mount Distance (A) | 43 mm |
Unit Type | MITSUBISHI |
Vacuum Pump | Yes |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MITSUBISHI | L 300 2.5 Diesel | (P05V,W,15V)[4D56] | 11.1986-05.1996 |
MITSUBISHI | L 300 2.5 Diesel | (PO5V,PO5W,P15V)[4D56] | 11.1986-05.1996 |
MITSUBISHI | L 300 2.5 Diesel | [4D56] | 11.1986-12.2000 |
Reference Information
ALT31052 40983RI A003T05499 56295 LRA01383 MD106320 28-1808 9020 A3T00599 A5012 11.0983M 2032134 EAA-221436 8EL737058-001 3730042750 210645 986046361 MD304129 11.0983 ALT6260 A002T10083 40983RIM 9213035 CGB-13005 LRA1383 A2T10083 MD141119 A003T00599 0986046361 DRA3377 MD313939 A3T05499 JA983IR SB123 MD111932R 20130141 MD111932 SA830 437147 111491 ALTF478 CAL32134GS ALT5040 20193431OEVideo/Publications
0986046361 11.0983 11.0983M 111491 20130141 20193431OE 2032134 28-1808 40983RI 40983RIM 437147 56295 8EL737058-001 9020 9213035 A3T00599 A3T05499 AEB1419 ALT31052 ALT6260 ALTF478 CAL32134GS CGB-13005 DRA3377 EAA-221436 JA983IR LRA01383 LRA1383 MD111932 MD141119 SA830 SB123 210645Add Your Number
