Associated Numbers
11.1184 112129 20130140 20137801BN 2035108 23718R 28-2804 401184RI 401184RIM 89213255 8EL737339-001 9213255 9368 A3T07483 A5004 AEA2235 ALT31011 CAL35108AS DRA3695 EAA-221473 JA1184IR LRA02717 MD162964 SA027 SA124 SA125Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | M8x1.25 mm |
| Diameter (D.3) | 8.5 mm |
| Grooves | 1 qty |
| Groove Width (W.1) | 15 mm |
| Length (L.1) | 218 mm |
| Mount Inside Length or Pad Mount C-C (C) | 54 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 50.5 mm |
| Outside Diameter (O.D.2) | 82 mm |
| Plug Code | PL_2004 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 46 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Vacuum Pump | Yes |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MITSUBISHI | Pajero 2.5 TD | (V24C,W)[4D56TD] | 12.1990-10.1993 |
Reference Information
112129 002-C302 ALC302 9368 SA027 SA125 JA1184IR SA124 23718N ALT31011 A5004 CGB-13695 23718R MD339609 MD162964 CAL35108AS LRA2717 A3T07483 2C302 401184RI ALT6220 EAA-221473 2035108 89213255 A003T07483 AEA2235 ALTS147 11.1184 20137801BN 210461 401184RIM 9213255 28-2804 DRA3695 ALT5406 20130140 ANM35915X 8EL737339-001 A12MH0681A2 LRA02717Video/Publications
002-C302 11.1184 112129 20130140 20137801BN 2035108 23718N 23718R 28-2804 2C302 401184RI 401184RIM 89213255 8EL737339-001 9368 A3T07483 A5004 AEA2235 ALC302 ALT31011 ALT6220 ALTS147 CAL35108AS CGB-13695 DRA3695 EAA-221473 JA1184IR LRA02717 LRA2717 MD162964 SA027 SA124 SA125 210461Add Your Number
