Remanufactured AS-PL Alternator
PREMIUM LINE
AS-PL
MAGNETI MARELLI
Price:
NZ$ 268.44 including GST
NZ$ 233.43 excluding GST
or four payments of $67.11
with
Learn More
UOM:
each
Product Code:
A4123PR
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
063321616010 20110216 210252 21216N 28-3577 301084RI 301084RIM 437814 4510 46420964 56327 57057Q 63320203 63320263 63321204 63321215 63321275 63321362 63321616 943321275010 944390900660 AG0236 DA4526 DRA3416 LRB00216 LRB216 MAN808 MAR5112 MRA90066Specifications
| Amp | 65 A |
| Bottom Mounting Foot Width (B) | 17 mm |
| Diameter (D.1) | 12.50 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | 12.50 mm |
| Length (L.1) | 188 mm |
| Mount Inside Length or Pad Mount C-C (C) | 82 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Premium Line |
| Product Type | Remanufactured |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.2) | 62 mm |
| Pulley to Mount Distance (A) | 41.50 mm |
| Pulley Type | Solid |
| Unit Type | MAGNETI MARELLI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROËN | JUMPY I Van (BS_, BT_, BY_, BZ_) 1.6 i | 1580SPI | 10.1995-08.2000 |
| CITROËN | JUMPY I Van (BS_, BT_, BY_, BZ_) 1.6 i | 220A2.000 | 10.1995-08.2000 |
| FIAT | BRAVO I (182_) 1.9 D | 160A7.000 | 10.1995-10.2001 |
| FIAT | Palio 1.0 | [178A1.000] | 04.1996-10.2003 |
| FIAT | Palio 1.0 | [178A3.011] | 04.1996-10.2003 |
| FIAT | PALIO (178_, 171_, 371_) 1.0 | 178A1.000 | 04.1996-10.2003 |
| FIAT | PALIO (178_, 171_, 371_) 1.0 | 178A3.011 | 04.1996-10.2003 |
| FIAT | PUNTO (176_) 1.7 D | 176B3.000 | 04.1994-09.1997 |
| FIAT | PUNTO (176_) 1.7 TD | 176A3.000 | 01.1994-09.1999 |
| FIAT | PUNTO (176_) 1.7 TD | 176A5.000 | 01.1994-09.1999 |
| FIAT | PUNTO (176_) 1.7 TD (176AT) | 176B7.000 | 09.1996-09.1999 |
| FIAT | Punto 1.7 D | [176B3.000] | 04.1994-09.1997 |
| FIAT | Punto 1.7 D | [176B3.000] | 04.1996-02.2000 |
| FIAT | Punto 1.7 TD | [176A3.000] | 01.1994-09.1999 |
| FIAT | Punto 1.7 TD | [176A5.000] | 01.1994-09.1999 |
| FIAT | Punto 1.7 TD | [176A5.000] | 04.1996-02.2000 |
| FIAT | PUNTO Van (176_) 1.7 D | 176B3.000 | 04.1996-02.2000 |
| FIAT | PUNTO Van (176_) 1.7 TD | 176A5.000 | 04.1996-02.2000 |
| FIAT | STRADA Pickup (178_, 278_) 1.7 TD | 176A3.000 | 06.1999-12.2006 |
Reference Information
| 063321616010 | MAGNETI MARELLI |
| 20104201BN | REAL |
| 20104201OE | REAL |
| 20104201RE | REAL |
| 20110216 | PRESTOLITE |
| 2030102.0 | SANDO |
| 2030102.1 | SANDO |
| 2030102.4 | SANDO |
| 210252 | ERA |
| 28-3577 | ELSTOCK |
| 437814 | VALEO |
| 4510 | CEVAM |
| 46000357 | FIAT |
| 46407645 | FIAT |
| 46420961 | FIAT |
| 46420964 | FIAT |
| 46420965 | FIAT |
| 46434932 | FIAT |
| 46464275 | FIAT |
| 46540293 | FIAT |
| 56327 | EAI |
| 57057Q | PEUGEOT |
| 5705GV | PEUGEOT |
| 5895029 | FIAT |
| 63320203 | MAGNETI MARELLI |
| 63320263 | MAGNETI MARELLI |
| 63321204 | MAGNETI MARELLI |
| 63321215 | MAGNETI MARELLI |
| 63321275 | MAGNETI MARELLI |
| 63321362 | MAGNETI MARELLI |
| 63321616 | MAGNETI MARELLI |
| 7721122 | FIAT |
| 7778020 | FIAT |
| 943321275010 | MAGNETI MARELLI |
| 944390900660 | MAGNETI MARELLI |
| AG0236 | GHIBAUDI |
| ALT2340A | SIOM |
| ALT9071 | ELECTROLOG |
| ALTF302 | 3EFFE |
| CAL30102AS | CASCO |
| CAL30102GS | CASCO |
| CAL30102OS | CASCO |
| DA4526 | DELCO |
| DRA3416 | DELCO |
| LRB00216 | LUCAS |
| LRB216 | LUCAS |
| MAN808 | MAGNETI MARELLI |
| MAR5112 | MAGNETI MARELLI |
| MRA90066 | MAGNETI MARELLI |
| STX100320 | STARDAX |
| STX100588 | STARDAX |
| STX100588R | STARDAX |
