Associated Numbers
0986081000 102211-8740 102211-8741 11.1949M 114099 195.910.080 20132772BN 20132772OE 2040277 23966N 23966R 27060-0Q020 27060-0Q021 28-5623 301949RI 301949RID 5702J2 57043 5705KJ 89212953 9090663 9212953 A4084 AEK3010 ALT30476 CA1949IR CAL40277AS CAL40277GS DAN1036 DRA0216 LRA03010 RAA11327 SB213 SB270Specifications
Amp | 80 A |
Bottom Mounting Foot Width (B) | 20 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 11 mm |
Diameter (D.3) | M10x1.25 mm |
Grooves | 6 qty |
Length (L.1) | 170 mm |
Mount Inside Length or Pad Mount C-C (C) | 40 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 58 mm |
Plug Code | PL_9104 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 29 mm |
Pulley Type | SOLID |
Unit Type | LUCAS/MARELLI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CITROEN | C1 1.0 | [CFA(384F)] | 06.2005- |
PEUGEOT | 107 1.0 | [CFA(384F)] | 06.2005- |
TOYOTA | Aygo 1.0 i | [1KR-FE] | 02.2005- |
Reference Information
20132772OE 9212953 89212953 11.1949M 0986081000 5702L1 301949RID AEK3010 A4084 SB213 ALTL124 20132772BN 9090663 301949RI CAL40277AS STA0442R DRA0216 5705NP 195.910.080 RAA11327 270600Q130 ALT6258 986081000 210830 27060-0Q100-00 27060-0Q130 23966R 5702J2 LRA3010 DAN1036 5705KJ CA1949IR 57043 2040277 270600Q100 23966N 28-5623 27060-00020 ALT2106 A12DE1140A2 114099 5705CP ANM32436X 27060-0Q020 27060-0Q021 RNL102211-8740 270600Q10000 SB270 102211-8741 CAL40277GS 27060-0Q100 102211-8740 LRA03010 ALT30476Video/Publications
0986081000 102211-8740 102211-8741 11.1949M 114099 195.910.080 20132772BN 20132772OE 2040277 23966N 23966R 27060-0Q020 27060-0Q021 28-5623 301949RI 301949RID 5702J2 57043 5705KJ 89212953 9090663 A4084 AEK3010 ALT30476 ALTL124 CA1949IR CAL40277AS CAL40277GS DAN1036 DRA0216 LRA03010 LRA3010 RAA11327 RNL102211-8740 SB213 SB270 210830Add Your Number
