Associated Numbers
11.1219 11.1219M 111584 20104441BN 20104441OE 20110327 2030144 22583N 28-2725 301219RI 301219RIM 4619 46420963 56501 63321253 63321340 89213841 8EL737287-001 9090203 9213841 AEA3229 ALT12053 CA1219IR CAL30144AS CAL30144GS DRA3767 EAA-221822 LRA01583Specifications
Amp | 85 A |
Bottom Mounting Foot Width (B) | 25 mm |
Diameter (D.1) | 12 mm |
Diameter (D.2) | 16.5 mm |
Diameter (D.3) | 12 mm |
Grooves | 5 qty |
Length (L.1) | 203 mm |
Mount Inside Length or Pad Mount C-C (C) | 71 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 60 mm |
Plug Code | PL_9104 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 59 mm |
Pulley Type | SOLID |
Unit Type | LUCAS/MARELLI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FIAT | Palio 1.6 16V | [178B3.000] | 04.1996- |
FIAT | Palio 1.6 16V | [178B3.000] | 04.1996-10.1999 |
FIAT | Punto 1.6 | [176A9.000] | 04.1994-04.1997 |
FIAT | Siena 1.2 | [178B5.000] | 09.1998- |
FIAT | Siena 1.6 16V | [178B3.000] | 09.1998- |
Reference Information
89213841 ALT12053 20104441BN 63321340 ALT90066 CA1219IR 46432733 ANM35987X LRA01583 209305 ALTS175 71721198 20104441OE 7788684 11.1219 DRA3767 ALT2120 301219RIM AEA3229 301219RI 9090203 8EL737287-001 11.1219M 46420963 111584 63321253 LRA1583 20110327 56501 CAL30144GS 4619 2030144 22583N EAA-221822 28-2725 ALT2250 9213841 CAL30144ASVideo/Publications
11.1219 11.1219M 111584 20104441BN 20104441OE 20110327 2030144 22583N 28-2725 301219RI 301219RIM 4619 46420963 56501 63321253 63321340 89213841 8EL737287-001 9090203 AEA3229 ALT12053 ALT2120 ALT2250 ALTS175 CA1219IR CAL30144AS CAL30144GS DRA3767 EAA-221822 LRA01583 LRA1583 209305Add Your Number
