Associated Numbers
11.1258 11.1258M 111802 1305709080 1315060080 20104621BN 20110292 2030126 21292N 28-2845 301258RI 32321620 437851 4510 46430110 46434930 56564 63321205 63321276 63321361 63321617 89213842 8EL737405-001 9090031 9213842 AEA2292 CA1258IR CAL30126AS DRA3646 LRB00292 SA050 SB067Specifications
Amp | 75 A |
Bottom Mounting Foot Width (B) | 16.5 mm |
Diameter (D.1) | 10.5 mm |
Diameter (D.2) | 12.5 mm |
Diameter (D.3) | 12.5 mm |
Grooves | 5 qty |
Length (L.1) | 190 mm |
Mount Inside Length or Pad Mount C-C (C) | 82.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 62.5 mm |
Plug Code | PL_9104 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 42 mm |
Pulley Type | SOLID |
Unit Type | LUCAS/MARELLI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FIAT | Ducato 1.9 Diesel | [230A2.000] | 03.1994-04.2002 |
FIAT | Ducato 1.9 Diesel Combinato | [230A2.000] | 06.1995-10.2001 |
FIAT | Ducato 1.9 TD | [230A3.000] | 03.1994-04.2002 |
FIAT | Ducato 1.9 TD | [230A4.000] | 08.1994-04.2002 |
Reference Information
ALTS114 89213842 9090031 63321361 ANM35866X 11.1258M 20104621OE 46430110 CA1258IR SA050 32321620 46434930 20104621BN ALT2400 437851 DRA3646 2030126.1 5895030 63321617 11.1258 LRB292 63321276 1305709080 46231763 STA0183R 301258RI 8EL737405-001 1315060080 AEA2292 DAN627 111802 SB067 RNL63341617 CAL30126GS 20110292 56564 28-2845 63321617010 4510 210079 PRAS114 9213842 LRB00292 63321205 21292N CAL30126AS 2030126Video/Publications
11.1258 11.1258M 111802 1305709080 1315060080 20104621BN 20110292 2030126 21292N 28-2845 301258RI 32321620 437851 4510 46430110 46434930 56564 63321205 63321276 63321361 63321617 89213842 8EL737405-001 9090031 AEA2292 ALT2400 ALTS114 CA1258IR CAL30126AS DRA3646 LRB00292 LRB292 RNL63341617 SA050 SB067 210079Add Your Number
