Associated Numbers
06E903023C 06E903023CX 2015545 20179545OE 28-6703 305.914.180 439840 440565 553978RIV 89215990 AEK3593 ALV3822 CAL15545 CAL15545AS CAL15545ES CAL15545GS CAL15545OS CAL15545RS DRA1413 FG18T122 LRA03593 UD14857A VAL439840Specifications
Amp | 180 A |
Bottom Mounting Foot Width (B) | 13.5 mm |
Diameter (D.1) | 8.5 mm |
Diameter (D.2) | 8.5 mm |
Diameter (D.3) | M8x1.25 mm |
Diameter (D.4) | M8x1.25 mm |
Grooves | 6 qty |
Length (L.1) | 186 mm |
Mount Inside Length or Pad Mount C-C (C) | 61 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 56 mm |
Plug Code | PL_2306 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 40 mm |
Pulley Type | SOLID |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VW | Touareg 3.0 V6 Hybrid | [CGEA] | 01.2012- |
VW | Touareg 3.0 V6 Hybrid | [CGFA] | 01.2012- |
VW | Touareg 3.0 V6 TSI | [CJTA] | 01.2010- |
Reference Information
115918 FG18T122 LRA3593 ALV3822 06E903023CX 2015545.1 6E903023C A3149 AEK3593 20179545OE ALT00423 PRAF234 89215990 UD14857A 305.914.180.500 A12VA0869AS CAL15545GS 440565 305.914.180.004 LRA03593 442474 28-6703 ALTF234 VAL439840 553978RIV DRA1413 06E903023C 6E903023CX 439840Video/Publications
06E903023C 06E903023CX 2015545 20179545OE 28-6703 305.914.180 439840 440565 553978RIV 89215990 AEK3593 ALTF234 ALV3822 CAL15545 CAL15545AS CAL15545ES CAL15545GS CAL15545OS CAL15545RS DRA1413 FG18T122 LRA03593 LRA3593 UD14857A VAL439840Add Your Number
