Associated Numbers
021903016K 021903016KX 205.414.190 90-25-1220 A-80629 AEG1454 ALH7531 ALH7531NW LR1190-941 UD13152A
021903016K VW
021903016KX VW
11473 EAI
2044101 PIC
205414190 PSH
LR1190941 Hitachi
UD13152A AS-PLList
AEG1454 AUTOELECTRO
A-80629 DIXIE
LR1190-941 HITACHI
ALH7531 KRAUF
ALH7531NW KRAUF
205.414.190 PSH
021903016K VW
021903016KX VW
90-25-1220 WILSON
Specifications
| Amp | 190 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 7 qty |
| Length (L.1) | 203 mm |
| Mount Inside Length or Pad Mount C-C (C) | 60.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 56 mm |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | SOLID |
| Unit Type | HITACHI |
| Voltage | 12 V |
| Water Cooled | Yes |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | Q7 3.6 FSi Quattro | [BHK] | 08.2006-05.2010 |
Reference Information
A-80629 LR1190-941 ALH7531NW 021903016KX AEG1454 UD13152A ALH7531 021903016K 90-25-1220 205.414.190Video/Publications
021903016K 021903016KX 205.414.190 90-25-1220 A-80629 AEG1454 ALH7531 ALH7531NW LR1190-941 UD13152AAdd Your Number
