Associated Numbers
114428 20145442BN 2020244 553174RI 553174RIV 8979673011 CAL20244AS LR180-512TSpecifications
| Amp | 100 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10 mm |
| Grooves | 1 qty |
| Groove Width (W.1) | 15.5 mm |
| Length (L.1) | 250 mm |
| Mount Inside Length or Pad Mount C-C (C) | 81.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 49 mm |
| Outside Diameter (O.D.2) | 82 mm |
| Plug Code | PL_2004 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 49.5 mm |
| Pulley Type | SOLID |
| Unit Type | HITACHI |
| Vacuum Pump | Yes |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ISUZU | ELF 5.0 | [4JH1] | 01.2002- |
Reference Information
553174RIV LR180512B 2020244 LR180513B LR180-512T 8972492093 8973272181 114428 553174RI ALT3207 LR180512 CAL20244AS 8979673011 LR160502C A2054 LR160502B LR180513 LR160502E LR160502 20145442BN HAL180512E LR180512E LR180512CVideo/Publications
114428 20145442BN 2020244 553174RI 553174RIV 8979673011 CAL20244AS LR180-512TAdd Your Number
