Associated Numbers
0986038501 11.0780 111316 20110341 20130132 20145411BN 2020114 23100-02N13 23100-02N17 23100-02N21 23100-43G05 23100-43G07 23100-43G09 28-2519 40662RI 40780RI 437685 56423 8EL730114-001 9094 9212763 AEA3242 ALT32179 CAL20114AS DRA3206 DRA3206N EAA-221660 JA780IR LR160-426 LR160-426E LR160-426S LR160-426T LR160-427 LR160-427C LR160-427S LR160-427T LRA01479Specifications
Amp | 60 A |
Bottom Mounting Foot Width (B) | 13 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | 10 mm |
Grooves | 2 qty |
Groove Width (W.1) | 12.5 mm |
Length (L.1) | 253 mm |
Mount Inside Length or Pad Mount C-C (C) | 81.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 58 mm |
Outside Diameter (O.D.2) | 84 mm |
Plug Code | PL_2004 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 43.5 mm |
Pulley Type | SOLID |
Unit Type | HITACHI |
Vacuum Pump | Yes |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Cabstar 2.3 Diesel | (F22)[TD23] | 10.1986-06.1992 |
NISSAN | Cabstar 2.7 Diesel | (F22)[TD27] | 10.1986-10.1988 |
NISSAN | Pick Up 2.5 Diesel | (D21)[TD25] | 08.1987-02.1998 |
NISSAN | Pick Up 2.5 Diesel 4WD | (D21)[TD25] | 03.1996-02.1998 |
NISSAN | Pick Up 2.7 Diesel 4WD | (D21)[TD27] | 09.1987-08.1991 |
NISSAN | TeRano 2.7 TD | (R20)[TD27T] | 02.1993-01.2002 |
NISSAN | TeRano 2.7 TD | (WD21)[TD27T] | 02.1989-10.1993 |
Reference Information
111316 23100-02N21 LR160-427C 2310006J01 20110341 40662RI 986038501 JA780IR 2D392 LR160-426T 445829 LR160-426S PRAL311V 210104 ALT3173 9212763 ALTL311V 11.078 ALT5090 40780RI 20130132 2020114 56423 ALT122310 LRA1479 23100-43G05 ALTL311 23100-43G07 23100-43G09 LR160-427S LR160-427T 437685 CAL20114AS 20145411BN ANM35426X LR160437S 28-2519 ALD392 ALTL311RR ALT221140 002-D392 LR160-436 PRAL311 LR160-437 311942 A12HT1187A2 DRA3206N LR160437 DRA3206 23100-06J01 LR160-436S LR160-436T LRA01479 LR160436S AEA3242 9094 ALT32179 23100-02N13-EP LR160-426E 0986038501 8EL730114-001 LR160-426 LR160-427 A2033 2310002N13EP 210135 23100-02N17 LR160-437T EAA-221660 LR160-437S 23100-02N13Video/Publications
002-D392 0986038501 11.0780 111316 20110341 20130132 20145411BN 2020114 23100-02N13 23100-02N17 23100-02N21 23100-43G05 23100-43G07 23100-43G09 28-2519 2D392 311942 40662RI 40780RI 437685 56423 8EL730114-001 9094 9212763 A2033 AEA3242 ALD392 ALT122310 ALT221140 ALT32179 ALT5090 ALTL311 ALTL311RR ALTL311V CAL20114AS DRA3206 DRA3206N EAA-221660 JA780IR LR160-426 LR160-426E LR160-426S LR160-426T LR160-427 LR160-427C LR160-427S LR160-427T LRA01479 LRA1479 PRAL311 PRAL311V 210104 210135Add Your Number
