Associated Numbers
0986037811 11.0673 11.0673M 111187 1204062 1204132 20100939 20145711BN 2020117 20819N 28-1589 40673RI 436724 56186 56287 89213118 8944719961 8944719963 8944719964 8970447790 8EL726388-001 9090003 9350 94471996 AEA9139 ALT32177 CAL20117AS DRA3275 EAA-221671 JA673IR LR170-411 LR170-411B LR170-411C LR170-411D LR170-411E LR170-411F LR170-411P LRA00939 SA631Specifications
Amp | 70 A |
Bottom Mounting Foot Width (B) | 13 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | 10 mm |
Groove Width (W.1) | 12.5 mm |
Grooves | 1 qty |
Length (L.1) | 241 mm |
Mount Inside Length or Pad Mount C-C (C) | 82 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 50 mm |
Outside Diameter (O.D.2) | 82 mm |
Plug Code | PL_4500 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Type | SOLID |
Pulley to Mount Distance (A) | 42 mm |
Unit Type | HITACHI |
Vacuum Pump | Yes |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
OPEL | Corsa A 1.5 Diesel | [15D(4EC1)] | 06.1987-03.1993 |
OPEL | Corsa A 1.5 TD | [15DT(T4EC1)] | 03.1988-03.1993 |
VAUXHALL | Nova 1.5 TD | [15DT(T4EC1)] | 01.1990-02.1993 |
VAUXHALL | Nova A 1.5 Diesel | [15D] | 08.1989-03.1993 |
VAUXHALL | Nova A 1.5 TD | [15DT(T4EC1)] | 01.1990-03.1993 |
VAUXHALL | Novavan 1.5 Diesel | [15D(4EC1)] | 01.1991-10.1994 |
Reference Information
CAL20117AS 6204058 90542406 A2020 ALT3130 549082 8970447790 986037811 LR170-411 PRAS968 89213118 SA631 56186 9512123 2020117 9350 97044779 DRA3275 CGB-13275 20145711BN ALT5440 11.0673M 20819N 11.0673 8944719961 R1030073 8944719960 1204062 8944719965 8944719963 8944719964 445722 LR170-411B 28-1589 LRA939 111187 210288 LR170-411C EAA-221671 LR170-411D 2U900 LR170-411E LR170-411F 9090003 LR170-411P 94471996 436724 002-U900 ALT32177 1204132 ANM35495X ALU900 JA673IR 0986037811 9163940 20100939 40673RI 56287 8-94471-996-5 8EL726388-001 AEA9139 ALTS968 LRA00939Video/Publications
002-U900 0986037811 11.0673 11.0673M 111187 1204062 1204132 20100939 20145711BN 2020117 20819N 28-1589 2U900 40673RI 436724 56186 56287 89213118 8944719961 8944719963 8944719964 8970447790 8EL726388-001 9090003 9350 AEA9139 ALT3130 ALT32177 ALT5440 ALTS968 ALU900 CAL20117AS CGB-13275 DRA3275 EAA-221671 JA673IR LR170-411 LR170-411B LR170-411C LR170-411D LR170-411E LR170-411F LR170-411P LRA00939 LRA939 PRAS968 SA631 210288Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Alternators.
