A0709S - Brand new AS-PL Alternator

Specifications

Amp	150 A
Bottom Mounting Foot Width (B)	14 mm
Diameter (D.1)	8.5 mm
Diameter (D.2)	8.5 mm
Diameter (D.3)	M8x1.25 mm
Diameter (D.4)	M8x1.25 mm
Grooves	7 qty
Length (L.1)	196 mm
Mount Inside Length or Pad Mount C-C (C)	61 mm
OEM Product	No
Outside Diameter (O.D.1)	56 mm
Plug Code	PL_2300
Product Line	Standard Line
Product Type	Brand new
Pulley to Mount Distance (A)	30.5 mm
Pulley Type	CLUTCH
Unit Type	BOSCH
Voltage	12 V

Vehicle Applications

Make	Model	Type	Year
PORSCHE	Cayenne 3.2 V6	[M02.2Y]	10.2003-09.2007
VW	Touareg 3.2 V6	[AZZ]	10.2002-11.2006
VW	Touareg 3.2 V6	[BAA]	10.2002-11.2006
VW	Touareg 3.2 V6	[BKJ]	10.2002-11.2006
VW	Touareg 3.2 V6	[BMV]	10.2002-11.2006
VW	Touareg 3.2 V6	[BMV]	10.2004-11.2006
VW	Touareg 3.2 V6	[BMX]	10.2002-11.2006
VW	Touareg 3.2 V6	[BRJ]	10.2002-11.2006
VW	Touareg 3.6 V6 FSi	[BHK]	10.2005-05.2010
VW	Touareg 3.6 V6 FSi	[BHL]	10.2005-05.2010

Reference Information

ALTS830 23346N 124615026 23346R LRA2346 UD20667A BOS0124615026 ALT1913 210606 CA1749IR ALT122540 0124615026 CAL10254GS 95560391701 305.565.150 57308 986047450 116173 ANM36383X 4661 LRA02346 90-15-5623 DRA4163 95560301700 0986047450 A-6521 021903026B 28-4848 20101452OE 89213182 PRAS830 ALB1749 2010254.1 CGB-84848 ALTS830RR

Video/Publications

0124615026 021903026B 0986047450 116173 20101452OE 2010254.1 210606 23346N 23346R 28-4848 305.565.150 4661 57308 89213182 90-15-5623 95560301700 A-6521 ALB1749 ALT122540 ALTS830 ALTS830RR BOS0124615026 CA1749IR CAL10254GS CGB-84848 DRA4163 LRA02346 LRA2346 PRAS830 UD20667A
