Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 547.73 including GST
NZ$ 476.29 excluding GST
or four payments of $136.93
with
Learn More
each
A0365
2
Associated Numbers
0124525201 0124525221 0124525222 0124525545 03F903023D 03F903023F 03F903023FX 0986082230 20101384OE 2010483 28-6614 553975RIB 89215515 9090919 AEK3504 CA2118IR CAL10483GS DRA0578 LRA03504 UD01770ASpecifications
| Amp | 140 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8 mm |
| Diameter (D.2) | 8 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 197 mm |
| Mount Inside Length or Pad Mount C-C (C) | 62 mm |
| OEM Product | No |
| Plug Code | PL_2300 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 50 mm |
| Pulley to Mount Distance (A) | 29 mm |
| Pulley Type | CLUTCH |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A3 1.2 TFSi | [CBZB] | 01.2010- |
| SEAT | Altea 1.2 TSi | [CBZB] | 01.2010- |
| SEAT | Altea XL 1.2 TSi | [CBZB] | 01.2010- |
| SEAT | Ibiza 1.2 TSi | [CBZB] | 01.2010- |
| SEAT | Leon 1.2 TSi | [CBZB] | 01.2010- |
| SEAT | Toledo 1.2 TSi | [CBZA] | 01.2012- |
| SEAT | Toledo 1.2 TSi | [CBZB] | 01.2012- |
| SKODA | Fabia 1.2 TSi | [CBZA] | 01.2010- |
| SKODA | Fabia 1.2 TSi | [CBZB] | 01.2010- |
| SKODA | Octavia 1.2 TSi | [CBZB] | 01.2010- |
| SKODA | Praktik 1.2 TSi | [CBZA] | 01.2010- |
| SKODA | Rapid 1.2 TSi | [CBZA] | 01.2012- |
| SKODA | Rapid 1.2 TSi | [CBZB] | 01.2012- |
| SKODA | Roomster 1.2 TSi | [CBZA] | 01.2010- |
| SKODA | Roomster 1.2 TSi | [CBZB] | 01.2010- |
| SKODA | Yeti 1.2 TSi | [CBZB] | 01.2009- |
| VW | Caddy 1.2 TSi | [CBZB] | 01.2010- |
| VW | Golf VI 1.2 TSi | [CBZA] | 01.2009- |
| VW | Golf VI 1.2 TSi | [CBZB] | 01.2009- |
| VW | Golf V Plus 1.2 TSi | [CBZA] | 01.2009- |
| VW | Golf V Plus 1.2 TSi | [CBZB] | 01.2009- |
| VW | Jetta 1.2 TSi | [CBZB] | 01.2011- |
| VW | Polo 1.2 TSi | [CBZB] | 01.2009- |
| VW | Polo 1.2 TSi | [CBZC] | 01.2009- |
Reference Information
LRA03504 0986082230 441944 UD102577A 553975RIB CAL10483GS ALT10231 PRAL576 28-6614 CA2118IR LRA3504 PRAL576B 9090919 0124525201 0124525222 0124525221 2010483 03F903023FX UD01770A AEK3504 CGB-10578 PRAF608 A12BH0865A2 ALTF608 03F903023F 0124525545 DRA0578 89215515 03F903023D 03F903023DX 209499 A0365 115765 20101384OE RNL8223 ALT124830 A12BH0865 ALTL576B 03F903023J ALTL576 ANM32798X CGB-10578RVideo/Publications
A0365View your shopping basket or Browse other items in Alternators.
