A0344 - Brand new AS-PL Alternator

Specifications

Amp	120 A
Diameter (D.1)	8 mm
Diameter (D.2)	9 mm
Diameter (D.3)	9 mm
Grooves	5 qty
Length (L.1)	195 mm
Outside Diameter (O.D.1)	57 mm
Pad mount thickness (E.1)	79 mm
Pad mount thickness (E.2)	79 mm
Pivot Foot Length (B)	79 mm
Pivot Inside Length (C)	56 mm
Plug Code	PL_2200
Pulley Type	CLUTCH
Pulley to Mount Distance (A)	33 mm
Unit Type	BOSCH
Voltage	12 V

Vehicle Applications

Make	Model	Type	Year
OPEL	Astra G 2.2 16V	[Z22SE]	01.2000-12.2005
OPEL	Signum 2.0 Turbo	[Z20NET]	01.2003-
OPEL	Signum 2.2 direct	[Z22YH]	01.2003-
OPEL	Vectra C 2.0 GTS	[Z20NET]	01.2003-12.2008
OPEL	Vectra C 2.2	[Z22SE]	01.2001-
OPEL	Vectra C 2.2	[Z22YH]	01.2001-
OPEL	Zafira A 2.2 16V	[Z22SE]	01.2000-12.2005

Reference Information

9388 2010340.1 28-4717 475.509.120 LRA2242 20101043BN UD10859A 11.1916 20101043OE 2010340 RNL425048 BOM UNIT 920-3168 11.1916M CAL10340AS DRA0533 55559583 57232 9048070 LRA02242 6204264 9512185 CA1916IR 93186763 93189251 93189272 AEC1740 R1530087 124425048 CAL10340GS 11043RW

Video/Publications

0124425048 11.1916 11.1916M 11043RW 20101043OE 2010340 28-4717 475.509.120 55559583 57232 6204264 9048070 93186763 93189251 93189272 9388 9512185 AEC1740 CA1916IR CAL10340GS DRA0533 LRA02242 LRA2242 R1530087 RNL425048 UD10859A UNIT BOM 920-3168
