Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Retail Price:
NZ$ 419.53 including GST
NZ$ 364.81 excluding GST
or four payments of $104.88
with
Learn More
each
A0307
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0120468140Associated Numbers
0120468140 0120468154 0120468162 063534681400 0986042350 112189 1516474R 19070066 1986A00162 20101236BN 2010632 210672 2319 23502N 301456RI 301456RIP 437447 48-3736 5001760274 5001838198 5006143948 5010306007 5010306801 576.002.080 75923 860561 89213178 8EL012584-181 8EL737661-001 90-15-6649 90-15-6649N AG0106 ALB1456 ALT0112 ALT20054 CA1456IR CAL10632 CAL10632AS CAL10632ES CAL10632GS CAL10632OS CAL10632RS DB3460 DRB2350 EAA-222205 LRA02502 LRA2502 MAN2007Specifications
| Amp | 80 A |
| Bottom Mounting Foot Width (B) | 27 mm |
| Diameter (D.1) | 8 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 11 mm |
| Length (L.1) | 190 mm |
| Mount Inside Length or Pad Mount C-C (C) | 72 mm |
| OEM Product | No |
| Plug Code | PL_9105 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Type | NO PULLEY |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| RENAULT V.I. | 135.08 4.1 | [MIDR04.02.26A/4] | 01.2000- |
| RENAULT V.I. | 135.09 4.1 | [MIDR04.02.26A/4] | 01.2000- |
| RENAULT V.I. | 135.10 4.1 | [MIDR04.02.26A/4] | 01.2000- |
| RENAULT V.I. | 150.08 4.1 | [DCi4B] | 10.2001- |
| RENAULT V.I. | 150.08 4.1 | [MIDR04.02.26B/4] | 01.2000- |
| RENAULT V.I. | 150.09 4.1 | [MIDR04.02.26B/4] | 01.2000- |
| RENAULT V.I. | 150.10 4.1 | [MIDR04.02.26B/4] | 01.2000- |
| RENAULT V.I. | 150.12 4.1 | [DCi4B] | 01.2000- |
| RENAULT V.I. | 150.12 4.1 | [MIDR04.02.26B/4] | 01.2000- |
| RENAULT V.I. | 180.08 4.1 | [DCi4C] | 10.2001- |
| RENAULT V.I. | 180.08 6.2 | [MIDR06.02.26V/4] | 01.2000- |
| RENAULT V.I. | 180.09 6.2 | [MIDR06.02.26V/4] | 01.2000- |
| RENAULT V.I. | 180.10 6.2 | [MIDR06.02.26V/4] | 01.2000- |
| RENAULT V.I. | 180.12 4.1 | [DCi4C] | 10.2001- |
| RENAULT V.I. | 180.12 6.2 | [MIDR06.02.26V/4] | 01.2000- |
| RENAULT V.I. | 210.08 6.2 | [MIDR06.02.26W/4] | 01.2000- |
| RENAULT V.I. | 210.09 6.2 | [MIDR06.02.26W/4] | 01.2000- |
| RENAULT V.I. | 210.10 6.2 | [MIDR06.02.26W/4] | 01.2000- |
| RENAULT V.I. | 210.12 6.2 | [MIDR06.02.26W/4] | 01.2000- |
| RENAULT V.I. | 210.13 6.2 | [MIDR06.02.26W/4] | 01.2000- |
| RENAULT V.I. | 210.14 6.2 | [MIDR06.02.26W/4] | 01.2000- |
| RENAULT V.I. | 210.15 6.2 | [MIDR06.02.26W/4] | 01.2000- |
| RENAULT V.I. | 210.16 6.2 | [MIDR06.02.26W/4] | 01.2000- |
| RENAULT V.I. | 210.16 6.2 | [MIDR06.02.26W/4] | 04.1996- |
| RENAULT V.I. | 210.18 6.2 | [MIDR06.02.26W/4] | 04.1996- |
| RENAULT V.I. | 210.19D 6.2 | [MIDR06.02.26W/4] | 04.1996- |
| RENAULT V.I. | 220.08 6.2 | [DCi6W] | 01.2000- |
| RENAULT V.I. | 220.10 6.2 | [DCi6W] | 01.2000- |
| RENAULT V.I. | 220.12 6.2 | [DCi6W] | 01.2000- |
| RENAULT V.I. | 220.12 6.2 | [DCi6W] | 10.2001- |
| RENAULT V.I. | 220.13 6.2 | [DCi6W] | 01.2000- |
| RENAULT V.I. | 220.14 6.2 | [DCi6W] | 01.2000- |
| RENAULT V.I. | 220.14 6.2 | [DCi6W] | 10.2001- |
| RENAULT V.I. | 220.15 6.2 | [DCi6W] | 10.2001- |
| RENAULT V.I. | 220.16 6.2 | [DCi6W] | 01.2000- |
| RENAULT V.I. | 220.16 6.2 | [DCi6W] | 10.2001- |
| RENAULT V.I. | 220.18 6.2 | [DCi6W] | 04.1996- |
| RENAULT V.I. | 220.18 6.2 | [DCi6W] | 10.2001- |
| RENAULT V.I. | 250.12 6.2 | [MIDR06.02.26Y/41] | 01.2000- |
| RENAULT V.I. | 250.13 6.2 | [MIDR06.02.26Y/41] | 01.2000- |
| RENAULT V.I. | 250.14 6.2 | [MIDR06.02.26Y/41] | 01.2000- |
| RENAULT V.I. | 250.15 6.2 | [MIDR06.02.26Y/41] | 01.2000- |
| RENAULT V.I. | 250.16 6.2 | [MIDR06.02.26Y/41] | 01.2000- |
| RENAULT V.I. | 250.16 6.2 | [MIDR06.02.26Y/41] | 04.1996- |
| RENAULT V.I. | 250.18 6.2 | [MIDR06.02.26Y/41] | 04.1996- |
| RENAULT V.I. | 250.19 6.2 | [MIDR06.02.26Y/41] | 04.1996- |
| RENAULT V.I. | 260.16 9.8 | [MIDR06.20.45C/4] | 04.1996- |
| RENAULT V.I. | 260.18 9.8 | [MIDR06.20.45C/4] | 04.1996- |
| RENAULT V.I. | 260.18 9.8 | [MIDR06.20.45C/4] | 06.1997- |
| RENAULT V.I. | 260.19 9.8 | [MIDR06.20.45C/4] | 04.1996- |
| RENAULT V.I. | 270.12 6.2 | [DCi6A] | 10.2001- |
| RENAULT V.I. | 270.13 6.2 | [DCi6A] | 10.2001- |
| RENAULT V.I. | 270.14 6.2 | [DCi6A] | 10.2001- |
| RENAULT V.I. | 270.16 6.2 | [DCi6A] | 10.2001- |
| RENAULT V.I. | 270.18 6.2 | [DCi6A] | 10.2001- |
| RENAULT V.I. | 300.16 9.8 | [MIDR06.20.45D/41] | 04.1996- |
| RENAULT V.I. | 300.16 9.8 | [MIDR06.20.45D/41] | 09.1996- |
| RENAULT V.I. | 300.18 9.8 | [MIDR06.20.45D/41] | 04.1996- |
| RENAULT V.I. | 300.18 9.8 | [MIDR06.20.45D/41] | 06.1997- |
| RENAULT V.I. | 300.18 9.8 | [MIDR06.20.45D/41] | 09.1996- |
| RENAULT V.I. | 300.19 9.8 | [MIDR06.20.45D/41] | 04.1996- |
| RENAULT V.I. | 300.19 9.8 | [MIDR06.20.45D/41] | 09.1996- |
| RENAULT V.I. | 300.26 9.8 | [MIDR06.20.45D/41] | 04.1996- |
| RENAULT V.I. | 300.26 9.8 | [MIDR06.20.45D/41] | 06.1997- |
| RENAULT V.I. | 300.26 9.8 | [MIDR06.20.45E/41] | 06.1997- |
| RENAULT V.I. | 300.26D 9.8 | [MIDR06.20.45D/41] | 04.1996- |
| RENAULT V.I. | 300 9.8 | [MIDR06.20.45R41] | 04.1998- |
| RENAULT V.I. | 320.18 11.1 | [DCi11G] | 08.2000- |
| RENAULT V.I. | 320.24 11.1 | [DCi11G] | 08.2000- |
| RENAULT V.I. | 320.26 11.1 | [DCi11G] | 01.2001- |
| RENAULT V.I. | 320.26 11.1 | [DCi11G] | 08.2000- |
| RENAULT V.I. | 320.26D 11.1 | [dCi11G] | 08.2000- |
| RENAULT V.I. | 340.18 9.8 | [MIDR06.20.45C/4] | 06.1997- |
| RENAULT V.I. | 340.18 9.8 | [MIDR06.20.45E/41] | 04.1996- |
| RENAULT V.I. | 340.18 9.8 | [MIDR06.20.45E/41] | 06.1997- |
| RENAULT V.I. | 340.19 9.8 | [MIDR06.20.45E/41] | 04.1996- |
| RENAULT V.I. | 340.24 9.8 | [MIDR06.20.45E/41] | 04.1996- |
| RENAULT V.I. | 340.26 9.8 | [MIDR06.20.45E/41] | 04.1996- |
| RENAULT V.I. | 340.26 9.8 | [MIDR06.20.45E/41] | 06.1997- |
| RENAULT V.I. | 340.26 9.8 | [MIDR06.20.45E/41] | 06.1997-01.2001 |
| RENAULT V.I. | 340.26D 9.8 | [MIDR06.20.45E/41] | 04.1996- |
| RENAULT V.I. | 340.32 9.8 | [MIDR06.20.45E/41] | 06.1997- |
| RENAULT V.I. | 340 9.8 | [MIDR06.20.45M41] | 04.1998- |
| RENAULT V.I. | 370.18 11.1 | [DCi11E] | 01.2001- |
| RENAULT V.I. | 370.18 11.1 | [DCi11E] | 08.2000- |
| RENAULT V.I. | 370.24 11.1 | [DCi11E] | 08.2000- |
| RENAULT V.I. | 370.26 11.1 | [DCi11E] | 01.2001- |
| RENAULT V.I. | 370.26 11.1 | [DCi11E] | 08.2000- |
| RENAULT V.I. | 370.26D 11.1 | [dCi11E] | 08.2000- |
| RENAULT V.I. | 370.32 11.1 | [DCi11E] | 01.2001- |
| RENAULT V.I. | 380 11.1 | [MIDR06.23.56A41] | 06.2000- |
| RENAULT V.I. | 385.18 11.1 | [MIDR06.23.56A/41] | 04.1996- |
| RENAULT V.I. | 385.18 11.1 | [MIDR06.23.56A/41] | 06.1997- |
| RENAULT V.I. | 385.18 11.1 | [MIDR06.23.56B/41] | 04.1996- |
| RENAULT V.I. | 385.19 11.1 | [MIDR06.23.56A/41] | 04.1996- |
| RENAULT V.I. | 385.19 11.1 | [MIDR06.23.56B/41] | 04.1996- |
| RENAULT V.I. | 385.24 11.1 | [MIDR06.23.56A/41] | 09.1996- |
| RENAULT V.I. | 385.24 11.1 | [MIDR06.23.56B/41] | 04.1996- |
| RENAULT V.I. | 385.24 11.1 | [MIDR06.23.56B/41] | 09.1996- |
| RENAULT V.I. | 385.26 11.1 | [MIDR06.23.56A/41] | 06.1997- |
| RENAULT V.I. | 385.26 11.1 | [MIDR06.23.56B/41] | 04.1996- |
| RENAULT V.I. | 385.32 11.1 | [MIDR06.23.56A/41] | 06.1997- |
| RENAULT V.I. | 400.18 11.1 | [MIDR06.23.56A/41] | 04.1996- |
| RENAULT V.I. | 400.18 11.1 | [MIDR06.23.56B/41] | 01.2000- |
| RENAULT V.I. | 400.18 11.1 | [MIDR06.23.56B/41] | 04.1996- |
| RENAULT V.I. | 400.18 12.0 | [MACKE.TECHA/46] | 05.2000- |
| RENAULT V.I. | 400.19 11.1 | [MIDR06.23.56A/41] | 04.1996- |
| RENAULT V.I. | 400.19 11.1 | [MIDR06.23.56B/41] | 04.1996- |
| RENAULT V.I. | 400.24 11.1 | [MIDR06.23.56A/41] | 04.1996- |
| RENAULT V.I. | 400.24 11.1 | [MIDR06.23.56A/41] | 09.1996- |
| RENAULT V.I. | 400.24 11.1 | [MIDR06.23.56B/41] | 09.1996- |
| RENAULT V.I. | 400.26 11.1 | [MIDR06.23.56A/41] | 04.1996- |
| RENAULT V.I. | 400.26 11.1 | [MIDR06.23.56B/41] | 01.2000- |
| RENAULT V.I. | 400.26 11.1 | [MIDR06.23.56B/41] | 09.1998- |
| RENAULT V.I. | 400.26 12.0 | [MACKE.TECHA/46] | 05.2000- |
| RENAULT V.I. | 400.32 11.1 | [MIDR06.23.56B/41] | 01.2000- |
| RENAULT V.I. | 420.18 11.1 | [DCi11C] | 01.2001- |
| RENAULT V.I. | 420.18 11.1 | [DCi11C] | 08.2000- |
| RENAULT V.I. | 420.26 11.1 | [DCi11C] | 01.2001- |
| RENAULT V.I. | 420.32 11.1 | [DCi11C] | 10.2001- |
| RENAULT V.I. | 420.34 11.1 | [DCi11C] | 01.2001- |
| RENAULT V.I. | 440.18 12.0 | [MACKE.TECHB/46] | 05.2000- |
| RENAULT V.I. | 440.24 12.0 | [MACKE.TECHB/46] | 05.2000- |
| RENAULT V.I. | 440.26 12.0 | [MACKE.TECHB/46] | 05.2000- |
| RENAULT V.I. | 480.18 12.0 | [MACKE.TECHC/46] | 05.2000- |
| RENAULT V.I. | 480.26 12.0 | [MACKE.TECHC/46] | 05.2000- |
| RENAULT V.I. | AE 390 12.0 | [MIDR06.24.65A/42] | 09.1996- |
| RENAULT V.I. | AE 420 12.0 | [MIDR06.35.40P/41] | 10.1992-12.1996 |
| RENAULT V.I. | AE 430 12.0 | [MIDR06.24.65B/42] | 01.1997- |
| RENAULT V.I. | AE 430 12.0 | [MIDR06.24.65B/42] | 01.1998- |
| RENAULT V.I. | AE 430 12.0 | [MIDR06.24.65B/42] | 09.1996- |
| RENAULT V.I. | AE 470 12.0 | [MIDR06.24.65C/42] | 01.1997- |
| RENAULT V.I. | AE 470 12.0 | [MIDR06.24.65C/42] | 01.1998- |
| RENAULT V.I. | AE 470 12.0 | [MIDR06.24.65C/42] | 11.1996- |
| RENAULT V.I. | AE 560 16.4 | [EE9-560] | 01.1997- |
| RENAULT V.I. | AE 560 16.4 | [EE9-560] | 01.1998- |
| RENAULT V.I. | AE 560 16.4 | [EE9-560] | 04.1996- |
| RENAULT V.I. | Agora 9.8 | [MIDR06.20.45I41] | 01.1996- |
| RENAULT V.I. | Ares 9.8 | [MIDR06.20.45M41] | 04.1998- |
| RENAULT V.I. | Ares 9.8 | [MIDR06.20.45R41] | 04.1998- |
| RENAULT V.I. | G 260.19 9.8 | [MIDR06.20.45C/4] | 02.1996-06.1997 |
| RENAULT V.I. | G 270.19 9.8 | [MIDR06.20.45B3] | 01.1993-10.1996 |
| RENAULT V.I. | G 300.19 9.8 | [MIDR06.20.45D/41] | 02.1996-06.1997 |
| RENAULT V.I. | G 300.26 9.8 | [MIDR06.20.45D/41] | 02.1996-06.1997 |
| RENAULT V.I. | G 340TI.26 9.8 | [MIDR06.20.45E3] | 10.1992-06.1997 |
| RENAULT V.I. | G 340TI.26 9.8 | [MIDR06.20.45E/41] | 10.1992-06.1997 |
| RENAULT V.I. | G 340TI.32 9.8 | [MIDR06.20.45E3] | 10.1992-06.1997 |
| RENAULT V.I. | G 340TI.32 9.8 | [MIDR06.20.45E/41] | 10.1992-06.1997 |
| RENAULT V.I. | G 340TI.40 9.8 | [MIDR06.20.45E3] | 10.1992-06.1997 |
| RENAULT V.I. | G 340TI.40 9.8 | [MIDR06.20.45E/41] | 10.1992-06.1997 |
| RENAULT V.I. | Iliade 9.9 | [MIDR06.20.45M41] | 10.1996-09.2001 |
| RENAULT V.I. | Iliade 9.9 | [MIDR06.20.45R41] | 10.1996-09.2001 |
| RENAULT V.I. | Line 9.9 | [MI7R06.20.45B41] | 05.1998- |
| RENAULT V.I. | Line 9.9 | [MI7R06.20.45C41] | 05.1998- |
| RENAULT V.I. | M 210.13 6.2 | [MIDR06.02.26W] | 05.1992-01.2000 |
| RENAULT V.I. | M 210.13 6.2 | [MIDR06.02.26W/41] | 05.1992-01.2000 |
| RENAULT V.I. | M 210.14 6.2 | [MIDR06.02.26W/41] | 05.1996-01.2000 |
| RENAULT V.I. | M 210.15 6.2 | [MIDR06.02.26W] | 05.1992-01.2000 |
| RENAULT V.I. | M 210.15 6.2 | [MIDR06.02.26W/41] | 05.1992-01.2000 |
| RENAULT V.I. | M 210.16 6.2 | [MIDR06.02.26W/41] | 05.1992-01.2000 |
| RENAULT V.I. | M 210.16 6.2 | [MIDR06.02.26W/41] | 05.1996-01.2000 |
| RENAULT V.I. | M 230.13 6.2 | [MIDR06.02.26Y/41] | 05.1996-01.2000 |
| RENAULT V.I. | M 250.13 6.2 | [MIDR06.02.26Y/41] | 05.1996-01.2000 |
| RENAULT V.I. | M 250.15 6.2 | [MIDR06.02.26Y/41] | 05.1996-01.2000 |
| RENAULT V.I. | M 250.16 6.2 | [MIDR06.02.26Y/41] | 05.1996-01.2000 |
Reference Information
AG0106 5010306801 5010306007 ALTL765B ALT1756 19070066 ALT376280 7421324077 8EL737661-001 48-3736 CAL10632RS 0986042350 ALTL765BR ALTL765P DB3460 ALTL765 89213178 A0307 ALT376280A 0120468140 ALB1456 LRA02502 CAL10632AS 5001760274 PRAL765B CAL10632ES ALT0112 5001859216 2010632 PRAL765BR 210672 437447 75923 576.002.080 2319 23502N 90-15-6649 7485003228 301456RI 112189 441603 8EL012584-181 5001860274 0120468154 20101236BN 5006143948 5610057 50103306801 A24BH0061 RNL4235 A24BH0061A2 5010480878 301456RIP CGB-12350 ALT6820 PRAL765P 1516474R ALT20054 DRB2350 860561 5001838198 0120468162 063534681400 ALT176020 5010306710 ANM44570X CAL10632GS 5001306801 90-15-6649N CAL10632OS 1986A00162 LRA2502 MAN2007 ALT2092NP CAL10632 CA1456IR PRAL765 CGB-83736Video/Publications
